Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour RAIDON
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano STePS E8010, 500Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Subvert I/O X6 Aluminum frame for Shimano STePS E7000, Tapered head tube
Suspension Fork
SR Suntour Raidon 34mm, Boost LOR-DS 27.5" Plus, 120mm travel, 15mm Thru-Axle, w/ Hydraulic Lockout
Drivetrain
Rear Derailleur
Shimano Deore, RD-M6000, 10-spd, Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano Deore RapidFire+ 10-spd
Cassette
Shimano Deore HG-500, 10-spd, 11-42T
Crank
Shimano E7000 forged, 34T Chainring
Bottom Bracket
N/A
Chain
KMC e10S Sport
Pedals
N/A
Wheels
Front Hub
Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle
Rear Hub
Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle
Rims
Weinmann U-40 TL, Tubeless Ready, 27.5"x40mm, Double Wall
Tires
Kenda HAVOC 27.5x2.8", 120tpi, Aramid beads, Tubeless Compatible
Brakes
Brakes
New Tektro HD-M735 hydraulic, 4-Piston front, 2-Piston rear, 203/180mm rotors
Brake Levers
New Tektro HD-M735
Cockpit
Stem
New Pivit 3D Forged alloy 60mm
Handlebar
New Pivit Alloy riser bar, 760mm wide; 20mm rise
Headset
FPD Dozer 1-1/8"-1.5", w/ Bottom AC Bearing, 8mm Cone
Seat
Saddle
WTB Volt Sport Wide 150mm
Seatpost
Pivit Light, 2 Bolts, Forged alloy, 31.6x 350 / 400mm
Motor & Battery
Motor
Shimano STePS E7000, 250 W, 60Nm Torque
Battery
Shimano STePS E8010, 500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.36 mm | 1.35 mm | 1.33 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 713 mm | 729 mm | 760 mm | 777 mm | 793 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 98 mm | 99 mm | 99 mm | 97 mm | 97 mm |
| Stack | 602 mm | 611 mm | 620 mm | 629 mm | 638 mm |
| Reach | 415 mm | 428 mm | 455 mm | 467 mm | 479 mm |
| Top Tube Length | 572 mm | 587 mm | 617 mm | 632 mm | 642 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 368 mm | 410 mm | 457 mm | 521 mm | 559 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1171 mm | 1187 mm | 1218 mm | 1235 mm | 1251 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 770 mm | 777 mm | 777 mm | 796 mm | 820 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Subvert i/O 5 is part of the Haro E Subvert model. There are 2 e-bikes that carry this model name. You can easily view all of the Haro E Subvert e-bikes models from 2019, here.
Model range prices
Haro Subvert i/O 5 2019 is the most economical model, with a starting price of 3249$. Haro Subvert i/O 9 2019 on the other hand costs 4849$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3249$. Doing a quick comparison, we notice that Subvert i/O 5 price is 3.57% smaller than the average cost of a Trail e-bike.
Overview of components
Fork
Haro Subvert i/O 5 2019 e-bike is equipped with the SunTour RAIDON fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Subvert i/O 5 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Haro Subvert i/O 5 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
