Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Revelation RC
-
Groupset XT Di2, Shimano -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano STePS E8010, 500Wh -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Subvert I/O X6 Aluminum frame for Shimano STePS E8000, Tapered head tube
Suspension Fork
New RockShox Revelation RC 27.5" Plus / 29" Boost, 35mm stanchions, 15mm Stealth Maxle, Debon Air, 130mm travel, w/ Hydraulic Lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT Di2, 11-spd, Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano XT Di2 11-spd Switch
Cassette
Shimano Deore XT M8000, 11-spd, 11-46T
Crank
Shimano E8000, forged, 38T Chainring
Bottom Bracket
N/A
Chain
KMC X11-E
Chain Guide
Shimano
Pedals
N/A
Wheels
Front Hub
Pivit Alloy disc Boost, E-Bike specific, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle
Rear Hub
Pivit Alloy disc Boost, E-Bike specific, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle
Rims
New WTB ST i35 TCS 2.0, Tubeless Ready, 27.5"x40mm, Double Wall
Tires
Kenda HAVOC 27.5x2.8", 120tpi, Aramid beads, Pro EMC, Tubeless Compatible
Brakes
Brakes
Shimano BR-MT520 / BL-MT501 Hydraulic Disc, 4-Piston, 203 / 180mm Rotors
Brake Levers
Shimano BL-MT501 Hydraulic
Cockpit
Stem
Race Face Aeffect R 35mm Forged short alloy
Handlebar
Race Face Ride Alloy 35mm bar, 20mm rise
Grips
WTB Ace, dual clamps, 135mm
Headset
FPD Dozer 1-1/8"-1.5", w/ Bottom AC Bearing, 8mm Cone
Seat
Saddle
WTB Volt Comp Wide 150mm
Seatpost
X-Fusion Manic 125 Dropper post w/ shifter-type remote, 7075 alloy, 31.6x125mmx400 / 100x360mm
Motor & Battery
Motor
Shimano STePS E8000, 250 W, 70Nm Torque
Battery
Shimano STePS E8010, 500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.69 mm | 1.61 mm | 1.51 mm | 1.49 mm | 1.47 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 662 mm | 676 mm | 713 mm | 729 mm | 744 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 95 mm | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 629 mm | 632 mm | 641 mm | 650 | 660 mm |
| Reach | 373 mm | 392 mm | 425 mm | 437 mm | 449 mm |
| Top Tube Length | 567 mm | 587 mm | 617 mm | 632 mm | 642 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 72.2 ° | 72.2 ° | 72.2 ° |
| Seat Tube Length | 368 mm | 406 mm | 457 mm | 520 mm | 559 mm |
| Head Tube Angle | 67.5 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1123 mm | 1137 mm | 1174 mm | 1190 mm | 1206 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 748 mm | 750 mm | 752 mm | 770 mm | 799 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Subvert i/O 9 belongs to the Haro E Subvert model. There are 2 e-bikes that carry this model name. Take a sneak peek at all Haro E Subvert e-bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Haro Subvert i/O 5 2019 has a starting price of 3249$. Haro Subvert i/O 9 2019 on the other hand is the most expensive at 4849$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 4849$. Comparing the average cost of a Trail e-bike to this one, you will see that Subvert i/O 9 price is 44.1% higher.
Subvert i/O 9 components
Fork
The Subvert i/O 9 comes factory-installed with the RockShox Revelation RC fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Subvert i/O 9 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the e-bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Haro Subvert i/O 9 e-bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
