Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork Fox Rhythm Float 34
-
Groupset X01 Eagle AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
Fox Float Rhythm 34, 120mm, Grip, 29”, 110x15
Drivetrain
Rear Derailleur
SRAM X01 Eagle AXS
Shift Levers
SRAM X01 AXS 2 Button Eagle Triggers
Cassette
SRAM XG 1295 EAGLE 10-50T
Crank
SRAM X01 Eagle (170mm or 175mm), DUB spindle, 32t Alloy Ring
Bottom Bracket
73mm English threaded
Chain
SRAM X01 EAGLE Powerlock 12 speed chain
Wheels
Rims
938 Alloy, Ibis Hubs (Ibis 933 wheelset with Step Cast fork upgrade)
Tires
Schwalbe Hans Dampf (front) Nobby Nic (rear) 29 x 2.6 (Racing Ray/Thunder Burt 29"x2.25” with Step Cast fork upgrade)
Brakes
Brakes
Shimano XT M8000 2 piston
Disk Rotors
Shimano SM-RT86 180 / 160
Cockpit
Stem
Thomson Elite X4 Stem (40, 50, 60, 70, 80, 90, 100, 110)
Handlebar
Ibis 800mm Carbon (10 or 30mm rise)
Grips
Lizard Skins Charger Evo
Headset
Cane Creek 40: ZS44/EC49
Seat
Saddle
WTB Silverado 142
Seatpost
Thomson 31.6 Elite, 367mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.57 mm | 1.52 mm | 1.46 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Trail | 99 mm | 99 mm | 99 mm | 99 mm |
| Stack | 622.3 mm | 639.3 mm | 645.3 mm | 660.3 mm |
| Reach | 386.3 mm | 407.3 mm | 424.3 mm | 451.3 mm |
| Top Tube Length | 584.3 mm | 609.3 mm | 630.3 mm | 660.3 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 368.3 mm | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 67.4 ° | 67.4 ° | 67.4 ° | 67.4 ° |
| Head Tube Length | 92 mm | 110 mm | 116 mm | 133 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1102 mm | 1138 mm | 1159 mm | 1194 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 699 mm | 769 mm | 769 mm | 794 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
DV9 X01 AXS completes the Ibis Dv9 model. 24 bikes variations carry this model name so far. Take a sneak peek at all Ibis Dv9 bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Ibis DV9 NX 2019 has a starting price of 2370$. Ibis DV9 XTR 2019 on the other hand is the most expensive at 7380$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Ibis released this model in 2019, its price was 5600$. Comparing the average cost of a Trail bike to this one, you will see that DV9 X01 AXS price is 102.75% more expensive.
Overview of components
Fork
Ibis DV9 X01 AXS 2019 bike is equipped with the Fox Rhythm Float 34 fork, and has 120mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The DV9 X01 AXS 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DV9 X01 AXS comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
