Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork Fox Rhythm Float 34
-
Groupset X01, X01 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
Fox Float Rhythm 34, 120mm, Grip, 29”, 110x15
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Eagle X01 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM Eagle X01 12 Speed
Cassette
SRAM XG 1295 EAGLE 10-50T
Crank
SRAM X01 Eagle 175, DUB spindle, 32t Alloy Ring
Bottom Bracket
73mm English threaded
Chain
SRAM X01 EAGLE Powerlock 12 speed chain
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Ibis
Rear Hub
Ibis
Rims
Ibis 938 Alloy, Ibis Hubs (Ibis 933 wheelset with Step Cast fork upgrade)
Tires
Schwalbe Hans Dampf (front) Nobby Nic (rear) 29 x 2.6 (Racing Ray/Thunder Burt 29"x2.25” with Step Cast fork upgrade)
Brakes
Brakes
Shimano XT M8000 2 piston
Brake Levers
Shimano XT M8000
Disk Rotors
Shimano SM-RT86 180 / 160
Cockpit
Stem
Thomson Elite X4 Stem (40, 50, 60, 70, 80, 90, 100, 110)
Handlebar
Ibis 800mm Carbon (10 or 30mm rise)
Grips
Lizard Skins Charger Evo
Headset
Cane Creek 40: ZS44/EC49
Seat
Saddle
WTB Silverado 142
Seatpost
Thomson 31.6 Elite, 367mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.57 mm | 1.52 mm | 1.46 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Trail | 99 mm | 99 mm | 99 mm | 99 mm |
| Stack | 622.3 mm | 639.3 mm | 645.3 mm | 660.3 mm |
| Reach | 386.3 mm | 407.3 mm | 424.3 mm | 451.3 mm |
| Top Tube Length | 584.3 mm | 609.3 mm | 630.3 mm | 660.3 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 368.3 mm | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 67.4 ° | 67.4 ° | 67.4 ° | 67.4 ° |
| Head Tube Length | 92 mm | 110 mm | 116 mm | 133 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1102 mm | 1138 mm | 1159 mm | 1194 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 699 mm | 769 mm | 769 mm | 794 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
DV9 X01 Eagle completes the Ibis Dv9 model. 24 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Ibis DV9 NX 2019 is the most economical model, with a starting price of 2370$. Ibis DV9 XTR 2019 on the other hand costs 7380$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2019 and its price was 4629$. Doing a quick comparison, we notice that DV9 X01 Eagle price is 67.6% higher than the average cost of a Trail bike.
DV9 X01 Eagle components
Fork
This bike has the Fox Rhythm Float 34 fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the DV9 X01 Eagle bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DV9 X01 Eagle comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
DV9 X01 Eagle comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
