Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Factory Float 32
-
Groupset XX1, XX1 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
Fox Shox Float Factory Fit4 32 Step Cast 100mm, 29”, 110x15
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Eagle XX1 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM Eagle XX1 12 Speed
Cassette
SRAM XG 1299 EAGLE 10-50T
Crank
SRAM XX1 Eagle 175, DUB spindle, 32t Alloy Ring
Bottom Bracket
73mm English threaded
Chain
SRAM Eagle XX1 with Power Lock, 12 speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Industy Nine
Rear Hub
Industy Nine
Rims
Ibis 935 Carbon, i9 Hubs
Tires
Schwalbe Racing Ray (front), Thunder Burt (rear), Snakeskin, 29"x2.25”
Brakes
Brakes
Shimano XTR M9100 2 piston
Brake Levers
Shimano XTR M9100
Disk Rotors
Shimano SM-RT86 180 / 160
Cockpit
Stem
Enve Mtn Stem 31.8mm (40, 55, 70mm)
Handlebar
Enve M6 Bar 800mm
Grips
Lizard Skins Charger Evo
Headset
Cane Creek 40: ZS44/EC49
Seat
Saddle
WTB Silverado Titanium 142mm
Seatpost
Enve Post 2 bolt, 31.6mm, 0mm offset, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.5 mm | 1.46 mm | 1.4 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm |
| Trail | 88 mm | 88 mm | 88 mm | 88 mm |
| Stack | 613.3 mm | 630.3 mm | 636.3 mm | 651.3 mm |
| Reach | 399.3 mm | 420.3 mm | 437.3 mm | 464.3 mm |
| Top Tube Length | 584.3 mm | 609.3 mm | 630.3 mm | 660.3 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 368.3 mm | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 92 mm | 110 mm | 116 mm | 133 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1102 mm | 1128 mm | 1149 mm | 1184 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 689 mm | 759 mm | 759 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
DV9 XX1 Eagle is part of the Ibis Dv9 model. Ibis launched 24 bikes of this model so far. Take a sneak peek at all Ibis Dv9 bikes models from 2019, by clicking here.
Model range prices
Ibis DV9 NX 2019 is the cheapest bike model and costs 2370$. Ibis DV9 XTR 2019 is the most expensive one and costs 7380$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2019 and its price was 7329$. Comparing the average cost of a Crosscountry bike to this one, you will see that DV9 XX1 Eagle price is 284.72% more expensive.
DV9 XX1 Eagle components
Fork
This bike has the Fox Factory Float 32 fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Ibis DV9 XX1 Eagle 2019, has a 29″ carbon model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
