Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 180mm -
Travel Rear 165mm -
Fork Fox Factory Float 38
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon front and rear triangle
Suspension Fork
Fox Float 38 Factory Series, 180mm, 29”, 110x15
Rear Shock
Fox Float X2 Factory Series with EVOL, 230mm x 65mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM XG 1275, 10-52T
Crank
SRAM NX Eagle, DUB, 32T Alloy Ring, 170mm
Bottom Bracket
Threaded (73mm BSA)
Chain
SRAM NX Eagle
Chain Guide
MRP AMg SE
Wheels
Rims
Blackbird Send Alloy, 32 Hole, F: Send I 29”, R: Send II 27.5”
Tires
Maxxis Assegai, 29” x 2.5” / Maxxis DHR, 27.5” x 2.4”
Brakes
Brakes
SRAM Code RSC, 4 Piston
Cockpit
Stem
Ibis 31.8mmS/M: 40mm, L/XL: 50mm
Handlebar
Ibis Aluminum, 780mm
Grips
Lizard Skin Charger Evo
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado
Seatpost
KS Rage-i DropperS: 125mm, M: 150mm, L/XL: 170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.444 mm | 1.377 mm | 1.313 mm | 1.256 mm | 1.203 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 769 mm | 795 mm | 823 mm | 855 mm | 895 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 621 mm | 625 mm | 630 mm | 638 mm | 651 mm |
| Reach | 430 mm | 454 mm | 480 mm | 508 mm | 541 mm |
| Top Tube Length | 585 mm | 610 mm | 630 mm | 655 mm | 685 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76.5 ° | 77 ° | 77.5 ° |
| Seat Tube Length | 400 mm | 400 mm | 406 mm | 450 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 81 mm | 86 mm | 91 mm | 100 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1202 mm | 1228 mm | 1256 mm | 1288 mm | 1328 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 725 mm | 735 mm | 752 mm | 765 mm | 769 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
HD6 GX completes the Ibis Hd6 model. There are 6 bikes that carry this model name. Take a sneak peek at all Ibis Hd6 bikes models from 2023, by clicking here.
Model range prices
Ibis HD6 GX 2023 is the most affordable bike of this model and has a price of 6099$. On the other hand, Ibis HD6 XX AXS 2023, is the most expensive and costs 11199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6099$. If we compare this with the average Enduro bike cost we notice that the price is 69.46% more expensive.
HD6 GX components
Fork
The fork installed on this bike is the Fox Factory Float 38 model. The travel on this model is 180mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Fox Float X2 Factory Series with EVOL model, with a travel of 165mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The HD6 GX 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The HD6 GX comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the HD6 GX. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
