Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 153mm -
Fork Fox Performance Float 36
-
Groupset NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX Float 36 Performance Series
Rear Shock
FOX Float DPX2 EVOL, 7.875" x 2.25"
Drivetrain
Rear Derailleur
SRAM NX, long cage, black, 11-speed
Front Derailleur
N/A
Shift Levers
SRAM NX, trigger, black, 11-speed
Cassette
SRAM PG 1130, 11-42 tooth, 11-speed
Crank
SRAM NX 175mm length
Bottom Bracket
Threaded 68mm
Chain
SRAM CN PC1110, 114 link with PowerLock
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Ibis, Boost
Rear Hub
Ibis, Boost
Rims
Ibis 738 Very Wide Asymmetric Wheelset, aluminum, 34mm inner width
Spokes
Pillar DB 14/15
Tires
Maxxis Minion DHF 2.6" WT or Schwalbe Nobby Nic 2.8” Plus
Brakes
Brakes
SRAM Level with centerline 180mm front/160mm rear rotors
Brake Levers
SRAM Level
Cockpit
Stem
Ibis 3D, forged 7075 aluminum, 31.8mm bar, 28.6mm steerer, 50 - 90mm length options
Handlebar
Ibis 7075 aluminum, 780mm wide, 20mm rise, 4 x 9º bend
Grips
Lizard Skins Logo
Headset
Cane Creek 40, ZS44/EC49
Seat
Saddle
Ibis custom saddle, chromoly rails
Seatpost
KS LEV-Si dropper with length options of 100mm, 125mm or 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.36 mm | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Stack | 566 mm | 586 mm | 601 mm | 616 mm |
| Reach | 411 mm | 431 mm | 451 mm | 476 mm |
| Top Tube Length | 575 mm | 600 mm | 624 mm | 654 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 362 mm | 393 mm | 445 mm | 483 mm |
| Head Tube Angle | 64.9 ° | 64.9 ° | 64.9 ° | 64.9 ° |
| Head Tube Length | 87 mm | 109 mm | 126 mm | 142 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1159 mm | 1188 mm | 1215 mm | 1247 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 689 mm | 711 mm | 725 mm | 753 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mojo HD4 SRAM NX is part of the Ibis Mojo model. Ibis launched 76 bikes of this model so far. You can easily view all of the Ibis Mojo bikes models from 2018, here.
Model range prices
The most economical model, the Ibis Mojo 3 NX 2018 has a starting price of 5856$. Ibis Mojo HD4 SRAM XX1 Eagle 2018 on the other hand is the most expensive at 9699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2018 and its price was 6256$. Comparing the average cost of an Enduro bike to this one, you will see that Mojo HD4 SRAM NX price is 73.83% higher.
Mojo HD4 SRAM NX components
Fork
Ibis Mojo HD4 SRAM NX 2018 bike is equipped with the Fox Performance Float 36 fork, and has 160mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is FOX Float DPX2 EVOL, with a travel distance of 153mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Ibis Mojo HD4 SRAM NX 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Mojo HD4 SRAM NX comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Ibis Mojo HD4 SRAM NX comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
