Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 153mm -
Fork Fox Factory Float 36
-
Groupset XX1, XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
Fox Float 36, Factory Series, Fit Grip 2, Kashima, 160mm, 27.5”, 15QR BOOST
Rear Shock
Fox Float Performance Series DPX2 7.875 x 2.25
Drivetrain
Rear Derailleur
SRAM Eagle XX1 12 Speed
Shift Levers
SRAM Eagle XX1 12 Speed
Cassette
SRAM XX1 Eagle 10-50T 12 Speed
Crank
SRAM XX1 Eagle 175, DUB spindle, 32t Alloy Ring
Bottom Bracket
SRAM DUB BSA
Chain
SRAM Eagle XX1 with Power Lock, 12 speed
Wheels
Rims
Ibis 742 Carbon, i9 Hubs
Tires
Maxxis 27.5 x 2.6 Minion DHF WT
Brakes
Brakes
Shimano Saint M820
Disk Rotors
Shimano SM-RT86 180
Cockpit
Stem
Enve Mtn Stem 31.8mm (40, 55, 70mm)
Handlebar
Enve Carbon DH Handlebar
Grips
Lizard Skins Charger Evo
Headset
Cane Creek 40 ZS44/ZS56
Seat
Saddle
WTB Silverado Team
Seatpost
Bike Yoke Revive Dropper (125, 160 or 185mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.36 mm | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 733 mm | 762 mm | 789 mm | 821 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 118 mm | 118 mm | 118 mm | 118 mm |
| Stack | 566 mm | 586 mm | 601 mm | 616 mm |
| Reach | 411 mm | 431 mm | 451 mm | 476 mm |
| Top Tube Length | 575 mm | 600 mm | 624 mm | 654 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 362 mm | 393 mm | 445 mm | 483 mm |
| Head Tube Angle | 64.9 ° | 64.9 ° | 64.9 ° | 64.9 ° |
| Head Tube Length | 87 mm | 109 mm | 126 mm | 142 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1159 mm | 1188 mm | 1215 mm | 1247 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 689 mm | 711 mm | 725 mm | 753 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mojo HD4 XX1 Eagle is an Ibis Mojo model. Ibis released 76 bikes variations of this model so far. Take a sneak peek at all Ibis Mojo bikes models from 2019, by clicking here.
Model range prices
Ibis Mojo 3 NX Eagle 2019 is the most economical model, with a starting price of 4099$. Ibis Mojo HD4 XX1 Eagle 2019 on the other hand costs 9599$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Ibis Mojo HD4 XX1 Eagle price was 9599$. If we compare this with the average Enduro bike cost we notice that the price is 166.71% higher.
Mojo HD4 XX1 Eagle components
Fork
The fork installed on this bike is the Fox Factory Float 36 model. The travel on this model is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Fox Float Performance Series DPX2 7.875 x 2.25 rear shock model, which has a travel of 153mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Ibis Mojo HD4 XX1 Eagle 2019, has a 27.5″ carbon model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Ibis Mojo HD4 XX1 Eagle bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Ibis Mojo HD4 XX1 Eagle includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
