Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset GX, Truvativ Descendant -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 34 Float Performance Series
Rear Shock
FOX Float DPS Performance Series EVOL, 7.25" x 1.75"
Drivetrain
Rear Derailleur
SRAM Eagle GX, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM Eagle GX, trigger, 12-speed
Cassette
SRAM GX Eagle X-Glide, 10 x 50 tooth, 12-speed
Crank
SRAM Descendant, aluminum
Bottom Bracket
73mm (BSA) english thread
Chain
SRAM Eagle GX with PowerLock
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Ibis, Boost
Rear Hub
Ibis, Boost
Rims
Ibis 938 Very Wide Aluminum Asymmetric Wheelset, 34mm inner width
Spokes
Pillar DB 14/15
Tires
Schwalbe Nobby Nic 2.6”
Brakes
Brakes
Shimano BL/BR-M615 with 180mm front/160mm rear rotors
Brake Levers
Shimano BL/BR-M615
Cockpit
Stem
Ibis 3D, forged 7075 aluminum, 31.8mm bar, 28.6mm steerer, 50mm - 90mm lengths
Handlebar
Ibis T76 7075 aluminum, 780mm, 20mm rise
Grips
Lizard Skins Logo
Headset
Cane Creek 40 ZS44/EC49
Seat
Saddle
Ibis custom saddle, chromoly rails
Seatpost
KS LEV-Si Dropper, 100mm, 125mm or 150mm lengths
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.46 mm | 1.41 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Stack | 621 mm | 627 mm | 634 mm |
| Reach | 413 mm | 430 mm | 450 mm |
| Top Tube Length | 602 mm | 621 mm | 642 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 419 mm | 470 mm | 521 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 93 mm | 102 mm | 107 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1142 mm | 1169 mm | 1189 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm |
| Standover Height | 742 mm | 742 mm | 752 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Ripley LS GX Eagle completes the Ibis Ripley model. Ibis released 59 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Ibis Ripley LS NX 2018 is the most affordable bike of this model and has a price of 5856$. On the other hand, Ibis Ripley LS XX1 Eagle 2018, is the most expensive and costs 9299$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6556$. Doing a quick comparison, we notice that Ripley LS GX Eagle price is 137.36% more expensive than the average cost of a Trail bike.
Ripley LS GX Eagle components
Fork
Ibis Ripley LS GX Eagle 2018 bike is equipped with the Fox Performance Float 34 fork, and has 130mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the FOX Float DPS Performance Series EVOL rear shock model, which has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Ibis Ripley LS GX Eagle 2018, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ripley LS GX Eagle has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Ibis Ripley LS GX Eagle bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Ibis Ripley LS GX Eagle includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
