Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Size Specific Design Double-butted chromoly frame, extended head tube with reinforced collars, double tapered chromoly stays, forged dropouts and fender/rack eyelets/th>
Suspension Fork
Steel unicrown, bulge butted steerer, low-rider carrier mounts and forged dropouts with double fender eyelets
Drivetrain
Rear Derailleur
Shimano Tourney TY500
Front Derailleur
TY510
Shift Levers
Shimano EZ-Fire Plus EF41 shifters, 21-speed
Cassette
Shimano HG200 7-speed, 12-32T
Crank
Shimano FC-TY301, 48/38/28T, 170mm (14-18”), 175mm (21-23")
Bottom Bracket
VP sealed cartridge, 68 x 122.5mm
Chain
KMC Z51
Pedals
Platform style, steel cage/resin body, toe clip attachable
Wheels
Rims
Double wall alloy rims, 32H, alloy hubs with QR and 14g stainless steel spokes
Tires
Kenda K-197 Eurotrek, 700 x 32c
Brakes
Brakes
Promax TX-121 alloy linear-pull brakes with front power modulator and Shimano brake levers
Cockpit
Stem
Jamis alloy hi-rise, quill type, 25.4 x 80mm extension x 35? x 150mm (15/17”), 180mm (19/21/23")
Handlebar
Jamis Riser bar, alloy 25.4 x 10? sweep x 40mm rise x 600mm length
Grips
Anatomic double density kraton
Headset
Threaded, 1 1/8”
Seat
Saddle
Jamis Touring with SL cover
Seatpost
Jamis alloy micro-adjust, 27.2 x 350mm alloy clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.45 mm | 1.5 mm | 1.54 mm | 1.58 mm |
| Front Center | 598 mm | 614 mm | 626 mm | 627 mm | 639 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 61 mm | 61 mm | 54 mm | 54 mm |
| Stack | 543 mm | 567 mm | 590 mm | 614 mm | 637 mm |
| Reach | 385 mm | 390 mm | 394 mm | 399 mm | 404 mm |
| Top Tube Length | 552 mm | 564 mm | 575 mm | 587 mm | 599 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 112 mm | 138 mm | 165 mm | 186 mm | 210 mm |
| Chainstay Length | 428 mm | 433 mm | 433 mm | 438 mm | 438 mm |
| Wheelbase | 1019 mm | 1040 mm | 1053 mm | 1059 mm | 1071 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 728 mm | 759 mm | 800 mm | 837 mm | 868 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
CODA completes the Jamis Coda model. Jamis launched 32 bikes of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Jamis CODA STEP-OVER 2019 has a starting price of 429$. Jamis CODA ELITE 2019 on the other hand is the most expensive at 979$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fitness bikes average price
Our math shows that the average cost of a dependable Fitness bike is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Jamis CODA price was 429$. Doing a quick comparison, we notice that CODA price is 52.91% lower than the average cost of a Fitness bike.
Average weight for Fitness bikes
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Jamis CODA it’s weighing 12.36 kg (27.25 lbs). At this weight, is a bit heavier than average. In other words, this model is 9.96% heavier than the average Fitness bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When it comes to wheels, the CODA bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Jamis CODA is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
