Jamis HIGHPOINT A1 2023
2023 Mountain
Estimate price |
1,249$
Weight | 13.95 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061triple-butted aluminum main tubes, 1.5 – 1 1/8” tapered head tube, over-sized stays, replaceable derailleur hanger
Suspension Fork
Rock Shox Judy Silver TK 29”, Solo Air compression, external rebound, Turn Key lockout, 30mm steel stanchions, magnesium lowers, 15x110mm axle, 120mm travel, 51mm rake
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus rear, 11-speed
Shift Levers
Shimano Deore, 1×11-speed
Cassette
Shimano HG5100, 11-speed, 11-51T
Crank
Shimano Deore, 32T
Bottom Bracket
Shimano BSA
Chain
KMC X11, 11-speed
Pedals
MTB platform, hi-impact resin
Wheels
Rims
WTB STX i23 TCS tubeless 29” rims, 32H, alloy disc hubs, 14G black electroplated spokes
Tires
WTB Trailboss, 29 x 2.25”
Brakes
Brakes
Shimano MT200 hydraulic disc, Shimano RT26 160mm rotors
Cockpit
Stem
Jamis XC alloy threadless, 31.8 x 60mm
Handlebar
Jamis XC alloy riser, 31.8 x 20mm rise x 740mm
Grips
Kraton
Headset
Zero-stack internal cup, 15mm cone spacer
Seat
Saddle
Selle Royal Vivo
Seatpost
Jamis alloy micro-adjust, 31.6 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.47 mm | 1.42 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 693 mm | 719 mm | 745 mm | 770 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 96 mm | 96 mm | 96 mm | 96 mm |
| Stack | 629 mm | 638 mm | 647 mm | 657 mm |
| Reach | 397 mm | 419 mm | 441 mm | 464 mm |
| Top Tube Length | 579 mm | 604 mm | 629 mm | 654 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1120 mm | 1146 mm | 1172 mm | 1198 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 757 mm | 793 mm | 830 mm | 862 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
HIGHPOINT A1 is a Jamis Highpoint model. Jamis released 10 bikes variations of this model so far. Take a sneak peek at all Jamis Highpoint bikes models from 2023, by clicking here.
Model range prices
Jamis HIGHPOINT A2 2023 is the most economical model, with a starting price of 999$. Jamis HIGHPOINT A1 2023 on the other hand costs 1249$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Jamis released this model in 2023, its price was 1249$. If we compare this with the average Trail bike cost we notice that the price is 121.14% smaller.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 13.95 kg (30.75 lbs), Jamis bike is a bit heavier than average. In conclusion, the average Trail bike weighs 7.47% less than HIGHPOINT A1.
Overview of components
Fork
The RockShox Judy Silver TK is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
When leaving the production line, the HIGHPOINT A1 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The HIGHPOINT A1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Jamis HIGHPOINT A1 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
