kalkhoff IMAGE 3 EXCITE Wave 2023
2023 E-bike
Estimate price |
4,950$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Fork Suntour NEX -
Groupset Nexus -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube Li-Ion 36 V -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Integrale 3|23
Suspension Fork
SR Suntour NEX E25 HLO, lockout
Rear Shock
No
Drivetrain
Shift Levers
Shimano Nexus
Crank
aluminium
Bottom Bracket
Integrated in Drive Unit
Chain
Gates Carbondrive CDX
Pedals
Comfort, aluminium
Wheels
Front Hub
Shimano TX505, QR
Rear Hub
Shimano Nexus, 5 speed,Shimano Nexus, 5-Gang
Rims
Aluminium, hollow section, eyelets
Tires
Schwalbe Energizer Plus Performance, 50-622
Brakes
Brakes
disc brake
Cockpit
Stem
Aluminium, adjustable
Handlebar
Tour, Aluminium
Seat
Saddle
Selle Royal Essenza Plus
Seatpost
Patent, suspension
Motor & Battery
Motor
Bosch Performance Line Smart System, 36 V / 250 W / 75 Nm
Battery
Bosch PowerTube Li-Ion 36 V
Charger
Bosch, 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XL | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.484 mm | 1.655 mm | 1.674 mm | 1.673 mm |
| Front Center | 672 mm | 714 mm | 717 mm | 727 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 10 mm | 19 mm | 19 mm |
| Stack | 685.7 mm | 653.7 mm | 663.1 mm | 672.5 mm |
| Reach | 462 mm | 395 mm | 396 mm | 402 mm |
| Top Tube Length | 618.3 mm | 649.9 mm | 652.7 mm | 661.6 mm |
| Seat Tube Angle | 73 ° | 73 ° | 70 ° | 73 ° |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70 ° | 70 ° |
| Head Tube Length | 195 mm | 165 mm | 175 mm | 180 mm |
| Chainstay Length | 494 mm | 494 mm | 494 mm | 494 mm |
| Wheelbase | 1158 mm | 1200 mm | 1204 mm | 1213 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 650 | 650 | 650 | 650 |
Model Overview
IMAGE 3 EXCITE Wave completes the Kalkhoff E Image model. Kalkhoff released 59 e-bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Kalkhoff IMAGE 1.B MOVE INTERNATIONAL 2023 is the most affordable e-bike of this model and has a price of 2918$. On the other hand, Kalkhoff IMAGE 5.B EXCITE+ ABS Diamond 2023, is the most expensive and costs 6081$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter e-bikes average price
Our math shows that the average cost of a dependable Commuter e-bike is 2569$. However, this doesn’t mean that if you spend less money on a Commuter e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4499$. Comparing the average cost of a Commuter e-bike to this one, you will see that IMAGE 3 EXCITE Wave price is 75.13% more expensive.
IMAGE 3 EXCITE Wave components
Fork
The IMAGE 3 EXCITE Wave comes factory-installed with the Suntour NEX fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the IMAGE 3 EXCITE Wave e-bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The IMAGE 3 EXCITE Wave comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
