Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork Suntour M 3010
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Tour Profile - internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR M3010, 50 mm, coil spring (threaded steerer)
Drivetrain
Rear Derailleur
SHIMANO Altus M310 (direct mount)
Front Derailleur
SHIMANO TY710 (34.9 mm)
Shift Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cassette
SHIMANO CS-HG200-8 (12-32T)
Crank
SHIMANO TY301 (48x38x28T) - length 175 mm
Bottom Bracket
cartridge (120 mm)
Chain
KMC Z8 (114 links)
Pedals
plastic
Wheels
Front Hub
alloy (32 holes)
Rear Hub
alloy (32 holes)
Rims
KLS Draft 622x21 (32 holes / eyelets)
Spokes
steel
Tires
INNOVA 42-622 (700x42C)
Brakes
Brakes
APSE V-brake
Brake Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cockpit
Stem
KALLOY adjustable - diam 25.4 mm / bar bore 25.4 mm / length 100 mm
Handlebar
steel RiseBar - diam 25.4 mm / rise 35 mm / width 630 mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
KLS CrossLine
Seatpost
KALLOY suspension - diam 30.9 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 700 | 700 |
Model Overview
CARSON 30 completes the Kellys Carson model. Kellys released 18 bikes variations of this model so far. You can easily view all of the Kellys Carson bikes models from 2023, here.
Model range prices
Kellys CARSON 10 2023 is the most economical model, with a starting price of 700$. Kellys CARSON 90 2023 on the other hand costs 1379$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter bikes average price
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 742$. Comparing this to the average Commuter bike price, we see that the price is 2.7% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
CARSON 30 components
Fork
The Suntour M 3010 is included from the factory. It has a travel distance of 50mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the CARSON 30 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CARSON 30 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
