Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Shimano, Tourney -
Suspension Hardtail -
Drivetrain Internally Geared Hub -
Brakes Rim
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Tour Profile - internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX, 63 mm, coil spring (threaded steerer)
Drivetrain
Shift Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cassette
SHIMANO CS-HG200-8 (12-32T)
Crank
SHIMANO TY301 (48x38x28T) - length 175 mm
Bottom Bracket
cartridge (120 mm)
Chain
KMC Z8 (114 links)
Pedals
plastic
Wheels
Front Hub
SHIMANO Dynamo Nexus C3000 / alloy (32 holes)
Rear Hub
SHIMANO Dynamo Nexus C3000 / alloy (32 holes)
Rims
KLS Draft 622x21 (32 holes / eyelets)
Spokes
steel
Tires
INNOVA 44-622 (700x42C)
Brakes
Brakes
TEKTRO V-brake
Brake Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cockpit
Stem
KALLOY adjustable - diam 25.4 mm / bar bore 25.4 mm / length 100 mm
Handlebar
steel RiseBar - diam 25.4 mm / rise 35 mm / width 630 mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
SELLE ROYAL Essenza Moderate
Seatpost
KALLOY suspension - diam 30.9 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
CARSON 50 completes the Kellys Carson model. There are 18 bikes that carry this model name. Take a sneak peek at all Kellys Carson bikes models from 2023, by clicking here.
Model range prices
Kellys CARSON 10 2023 is the most affordable bike of this model and has a price of 700$. On the other hand, Kellys CARSON 90 2023, is the most expensive and costs 1379$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter bikes average price
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Kellys released this model in 2023, its price was 806$. Comparing the average cost of a Commuter bike to this one, you will see that CARSON 50 price is 5.77% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
CARSON 50 components
Fork
This bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Kellys CARSON 50 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CARSON 50 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
CARSON 50 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
