Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Gravel Concept - Aluminium alloy Disc, flat mount, tapered HT, internal routing, 12x142 mm thru axle
Suspension Fork
KELLYS Carbon Disc - 1.5 tapered steerer, flat mount disc brake, 12x100 mm thru axle
Drivetrain
Rear Derailleur
SHIMANO Claris R2000 (direct mount)
Front Derailleur
SHIMANO Claris R2000 (brazed-on mount)
Shift Levers
SHIMANO Claris SL-R2000 Rapidfire Plus (for FlatBar)
Cassette
SHIMANO CS-HG50-8 (11-32T)
Crank
SHIMANO Claris R2000 (50x34T) - length 170 mm (S - M), 175 mm (L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC Z8 (112 links)
Wheels
Front Hub
NOVATEC Disc (32 holes)
Rear Hub
NOVATEC Disc (32 holes)
Rims
KELLYS Grind Disc 622x17 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Smart Sam Performance 42-622 (700x40C) ADDIX
Brakes
Brakes
TEKTRO Spyre Mechanical Disc
Brake Levers
SHIMANO Claris BL-R2000
Cockpit
Stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / 7° / length 70 mm (S ), 90 mm (M), 110 mm (L)
Handlebar
KLS Advanced FlatBar - diam 31.8 mm / width 720 mm
Grips
KLS Token 2Density
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active Road - diam 30.9 mm / length 350 mm (S), 400 mm (M - L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
SOOT 20 belongs to the Kellys Soot model. 16 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Kellys SOOT 20 2023 is the most affordable bike of this model and has a price of 1273$. On the other hand, Kellys SOOT 90 2023, is the most expensive and costs 2760$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 1273$. Comparing the average cost of a Gravel bike to this one, you will see that SOOT 20 price is 93.4% lower.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on SOOT 20 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kellys SOOT 20 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
SOOT 20 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
