Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Gold RL
-
Groupset SLX, Deore -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery KELLYS Re-Charge V10 Li-ion internal removable 725Wh / capacity 20Ah, powered by BMZ -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS TYGON R series - advanced robotic welded 6-series aluminium alloy, integrated removable battery, 1.5“ tapered HT, 12x148mm Boost thru axle / Made in EU
Suspension Fork
ROCK SHOX Recon GOLD RL (29) Boost, 120mm, DebonAir / Motion Control / Maxle Stealth 15mm thru axle
Drivetrain
Rear Derailleur
SHIMANO SLX M7100 (direct mount)
Shift Levers
SHIMANO Deore (021) SL-M6100-IR Rapidfire Plus (I-Spec EV)
Cassette
SHIMANO (021) CS-M6100-12 (10-51T)
Crank
SHIMANO E6100 (36T) - length 170mm
Chain
SHIMANO (021) CN-M6100 (122 links)
Pedals
plastic
Wheels
Front Hub
SHIMANO MT400-B / Deore MT410-B Disc Center Lock (15x110mm / 12x148mm / 32 holes)
Rear Hub
SHIMANO MT400-B / Deore MT410-B Disc Center Lock (15x110mm / 12x148mm / 32 holes)
Rims
KLS Valor 3 Disc 622x30 (32 holes)
Spokes
stainless steel black
Tires
SCHWALBE Nobby Nic Performance 60-622 (29x2.35) ADDIX
Brakes
Brakes
SHIMANO Deore (021) MT410 Hydraulic Disc
Brake Levers
SHIMANO Deore (021) BL-M4100
Disk Rotors
180mm front / 180mm rear
Cockpit
Stem
KLS Active - diam 28.6mm / bar bore 31.8mm / 6° / length 80mm
Handlebar
KLS Active RiseBar - diam 31.8mm / rise 18mm / width 720mm
Grips
KLS Poison OneLockon
Seat
Saddle
SELLE ROYAL Vivo
Seatpost
EXAform JAG1 Remote Telescopic - diam 30.9mm / length 485mm, travel 150mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V
Battery
KELLYS Re-Charge V10 Li-ion internal removable 725Wh / capacity 20Ah, powered by BMZ
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
TYGON R90 29″ 725Wh is a Kellys E Tygon model. Kellys launched 15 e-bikes of this model so far. Take a sneak peek at all Kellys E Tygon e-bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Kellys TYGON R10 P 29″ 725Wh 2022 has a starting price of 3184$. Kellys TYGON R90 P 29″ 725Wh 2022 on the other hand is the most expensive at 4246$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
TYGON R90 29″ 725Wh components
Fork
The fork installed on this bike is the RockShox Recon Gold RL model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on TYGON R90 29″ 725Wh are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The TYGON R90 29″ 725Wh has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the TYGON R90 29″ 725Wh. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
