Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RST
-
Groupset Deore, SLX -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
120mm, 4-bar Horst bearing linkage, Custom formed 6061 double butted alloy
Suspension Fork
RST First 32 Air, 120mm, hydraulic dampening, rebound adj, lock out, air spring, aly steerer
Rear Shock
RockShox Bar R, air w/hydraulic dampening & IFP, rebound adj, 190mm
Drivetrain
Rear Derailleur
Shimano RD-M592 Deore Shadow, Long Cage
Front Derailleur
Shimano FD-M661 SLX,Down Swing, direct mount
Shift Levers
Shimano SL-M430 Alivio Rapidfire, Pods
Cassette
Shimano CS-HG20-9, 11-34T, 9-speed
Crank
Shimano M430 Alivio, 44/32/22T, 15" = 170mm, 17"- 21" = 175mm, Ladies = 170mm
Bottom Bracket
Shimano, BB-ES25 Octalink, 68x118
Chain
KMC Z99 w/Missing Link
Pedals
Wellgo alloy ATB 1 pc.
Wheels
Rims
WTB SX17 Disc, 26x32H,Doublewall
Spokes
14G Black with alloy nipples, 32X32
Tires
Kenda Slant 6,26X2.1 Kevlar Folding ,60TPI
Brakes
Brakes
Avid Elixir 1 disc hydraulic,160mmRotors
Brake Levers
Avid Elixir 1
Cockpit
Stem
3D Forged Alloy, 4-bolt, 31.8, 10 degree, 15" = 80mm, 17" = 90mm, 19" = 100mm, 21" =110mm, Ladies = 80mm
Handlebar
Alloy 31.8 680X25mm, Ladies: 660X25mm
Grips
Q2 Lock-on
Headset
Cane Creek, 5ZS44, A-Head 1-1/8, Zero Stack, 44/30
Seat
Saddle
WTB Volt Sport, Black/White, Ladies: KHS Ladies Design
Seatpost
Alloy micro-adjust, 30.9x350mm
Model Overview
XC 204 (Ladies) completes the Khs Xc model. 13 bikes variations carry this model name so far. You can get a glimpse at all models from 2012, by clicking on this link.
Model range prices
The most economical model, the KHS XC 104 2012 has a starting price of 1249$. KHS XC TEAM 2012 on the other hand is the most expensive at 5299$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2012 for 1599$. In conclusion, this bike price is 72.73% lower than the price of the average Trail bike.
Overview of components
Fork
The XC 204 (Ladies) comes factory-installed with the RST fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Bar R model, with a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the XC 204 (Ladies) model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. KHS XC 204 (Ladies) has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
KHS XC 204 (Ladies) 2012 is available in one size only. In conclusion, make sure it fits you, or look for another model.
