Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver TK
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
120mm, 4-bar Horst bearing linkage, Custom formed 6061 double butted alloy
Suspension Fork
Rock Shox Recon Silver TK, Solo Air w/alloy steer tube, 120mm,Hydraulic dampening, Ext rebound + TurnKey Lockout
Rear Shock
X-Fusion E1RL air, hydrulic dampening, ext rebound adj & lock out
Drivetrain
Rear Derailleur
SRAM X9, Long Cage, 10-speed
Front Derailleur
SRAM X7, 3x10,High Direct Mount
Shift Levers
SRAM X5, 3x10
Cassette
SRAM PG-1030, 11-36T, 10-speed
Crank
SRAM S1000 3.3, 10S, alloy rings, 2pc, GXP, 44/33/22, S = 170mm,M-XL =175mm
Bottom Bracket
SRAM GXP outboard cartridge bearing
Chain
SRAM PC-1031
Pedals
Wellgo alloy ATB 1 pc.w/cnc sides
Wheels
Rims
WTB SX17 Disc, 26x32H,Doublewall
Spokes
14G Black with alloy nipples, 32X32
Tires
Kenda Slant 6, 26 X 2.1, Folding, 60 tpi
Brakes
Brakes
Avid Elixir 1 disc hydraulic,160mmRotors
Brake Levers
Avid Elixir 1
Cockpit
Stem
Kore Race, S = 80mm,M=90mm, L = 100mm, XL = 110mm
Handlebar
Kore Riser, 680X20mm,31.8
Grips
Q2 Lock-on
Headset
Cane Creek, ZS44 A-Head 1-1/8, Zero Stack, 44/30
Seat
Saddle
WTB Volt Comp, Black and Orange
Seatpost
Q2 Light Alloy, 30.9x350mm
About this model
XC 604 is a Khs Xc model. KHS released 13 bikes variations of this model so far. Take a sneak peek at all Khs Xc bikes models from 2012, by clicking here.
Model range prices
KHS XC 104 2012 is the cheapest bike model and costs 1249$. KHS XC TEAM 2012 is the most expensive one and costs 5299$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, KHS XC 604 price was 1999$. Comparing the average cost of a Trail bike to this one, you will see that XC 604 price is 38.17% lower.
Overview of components
Fork
KHS XC 604 2012 bike is equipped with the RockShox Recon Silver TK fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
XC 604 has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
The XC 604 has a rear shock with a travel of 120mm. The model X-Fusion E1RL air is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, KHS XC 604 2012, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. KHS XC 604 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike has one size only, so it might not fit you. In short, make sure you double-check if it fits you.
