Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 138mm -
Fork Fox Performance Elite Float 36
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM Slack
155cm - 171cm
SM Neutral
155cm - 171cm
MD Slack
169cm - 179cm
MD Neutral
169cm - 179cm
LG Slack
177cm - 189cm
LG Neutral
177cm - 189cm
XL Slack
187cm - 195cm
XL Neutral
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6066 Aluminum, Custom Titanium Hardware
Suspension Fork
Fox 36 29" Grip2 Performance Elite 150mm, 44mm offset
Rear Shock
RockShox Super Deluxe Ultimate RCT '22 185x55, CL RM
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
SRAM XG1275 Eagle 10-52T
Crank
SRAM GX Eagle 170 32T Ring
Bottom Bracket
SRAM DUB BSA SB+
Chain
SRAM GX Eagle
Wheels
Rims
Spank Oozy Trail 345 HEX 32h J-Bend (XD) OR RaceFace Aeffect R 30 Trace 28h J-Bend (XD)
Tires
Front: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO, Rear: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO
Brakes
Brakes
Magura MT5
Cockpit
Stem
Spank 35mm x 40mm
Handlebar
Spank 35mm x 800mm, 25mm Rise
Grips
Spank / SDG
Headset
FSA Orbit ZS44/56
Seat
Saddle
SDG Bel-Air V3
Seatpost
SDG Tellis 170mm, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Slack | SM Neutral | MD Slack | MD Neutral | LG Slack | LG Neutral | XL Slack | XL Neutral |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.36 mm | 1.36 mm | 1.31 mm | 1.31 mm | 1.27 mm | 1.27 mm |
| Bottom Bracket Height | 326 mm | 335 mm | 326 mm | 335 mm | 326 mm | 335 mm | 326 mm | 335 mm |
| Stack | 637 mm | 637 mm | 637 mm | 637 mm | 643 mm | 643 mm | 653 mm | 653 mm |
| Reach | 441 mm | 441 mm | 468 mm | 468 mm | 491 mm | 491 mm | 514 mm | 514 mm |
| Top Tube Length | 580 mm | 580 mm | 614 mm | 614 mm | 647 mm | 647 mm | 678 mm | 678 mm |
| Seat Tube Angle | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° |
| Seat Tube Length | 355 mm | 355 mm | 400 mm | 400 mm | 456 mm | 456 mm | 500 mm | 500 mm |
| Head Tube Angle | 65 ° | 65.75 ° | 65 ° | 65.75 ° | 65 ° | 65.75 ° | 65 ° | 65.75 ° |
| Head Tube Length | 108 mm | 108 mm | 108 mm | 108 mm | 115 mm | 115 mm | 125 mm | 125 mm |
| Chainstay Length | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm |
| Wheelbase | 1191 mm | 1191 mm | 1218 mm | 1218 mm | 1244 mm | 1244 mm | 1270 mm | 1270 mm |
| Bottom Bracket Drop | 48 mm | 39 mm | 48 mm | 39 mm | 48 mm | 39 mm | 48 mm | 39 mm |
| Standover Height | 696 mm | 696 mm | 724 mm | 724 mm | 775 mm | 775 mm | 788 mm | 788 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 155 cm | 169 cm | 169 cm | 177 cm | 177 cm | 187 cm | 187 cm |
| Rider Max Height | 171 cm | 171 cm | 179 cm | 179 cm | 189 cm | 189 cm | 195 cm | 195 cm |
About this model
Fugitive 138 GX is part of the Knolly Fugitive model. There are 21 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Knolly Fugitive 138 Deore 2023 has a starting price of 3099$. Knolly Fugitive 138 XT 2023 on the other hand is the most expensive at 6055$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Knolly released this model in 2023, its price was 5495$. If we compare this with the average Trail bike cost we notice that the price is 98.95% more expensive.
Overview of components
Fork
The Fugitive 138 GX comes factory-installed with the Fox Performance Elite Float 36 fork. This has a travel range of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Fugitive 138 GX has a rear shock with a travel of 138mm. The model RockShox Super Deluxe Ultimate RCT ’22 185×55 is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the Fugitive 138 GX bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Knolly Fugitive 138 GX has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 8 sizes. They vary from 155 cm – 195 cm (5.09 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Knolly Fugitive 138 GX includes a dropper post. Therefore, climbing or descending will be a breeze.
