Knolly Fugitive Extra Credit 2020
2020 Mountain
Estimate price |
5,180$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Fork RockShox Pike Ultimate
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike Ultimate RC2, 42mm offset
Rear Shock
Trunnion mount, 185mm x 50mm, Options: RockShox Super Deluxe Ultimate RCT, FOX FLOAT DPS Factory
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SHADOW RD+
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed, I-SPEC EV clamp
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth, HYPERGLIDE+
Crank
Shimano Deore XT M8130, 170mm length
Bottom Bracket
Shimano Deore XT MT800, 73mm BSA threaded
Chain
Shimano Deore XT M8100, 12-speed
Pedals
N/A
Wheels
Front Hub
Spank Oozy Trail 345 wheelset, j-bend, 32-hole, 6-bolt rotor mounts, 110x15mm Boost front, 157x12mm SuperBoost rear, Options: Industry Nine 1/1, j-bend, 28 hole, 6-bolt rotor mounts; Industry Nine Hydra, straight-pull, 28 hole, 6-bolt rotor mounts
Rear Hub
Spank Oozy Trail 345 wheelset, j-bend, 32-hole, 6-bolt rotor mounts, 110x15mm Boost front, 157x12mm SuperBoost rear, Options: Industry Nine 1/1, j-bend, 28 hole, 6-bolt rotor mounts; Industry Nine Hydra, straight-pull, 28 hole, 6-bolt rotor mounts
Rims
Spank Oozy Trail 345 wheelset, 32 hole, Option: Industry Nine Enduro-S, 28 hole
Spokes
Spank Oozy Trail 345 wheelset, j-bend, Options: Industry Nine Enduro-S wheelset, j-bend (1/1 hubs) or straight-pull (Hydra hubs)
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra, EXO, 29" x 2.3", Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO, 29" x 2.3"
Brakes
Brakes
Shimano Deore XT M8120, 4-piston, Shimano RT76 6-bolt rotors (203mm front, 180mm rear)
Brake Levers
Shimano Deore XT M8120
Cockpit
Stem
Race Face Aeffect R, 35mm bar clamp, 50mm length
Handlebar
Race Face Next R, 35mm clamp diameter, 800mm width, 20mm rise
Grips
Chromag Basis, black
Headset
Cane Creek 40 Series, ZS44 upper, ZS56 lower
Seat
Saddle
Chromag Lynx DT
Seatpost
Race Face Turbine R dropper, 175mm drop, 1x Turbine R remote lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.36 mm | 1.29 mm | 1.24 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Stack | 618 mm | 618 mm | 622.5 mm | 629 mm |
| Reach | 427 mm | 456 mm | 483 mm | 506 mm |
| Top Tube Length | 583 mm | 612 mm | 640 mm | 664 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 355 mm | 400 mm | 456 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 98 mm | 98 mm | 103 mm | 110 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1162 mm | 1190 mm | 1220 mm | 1245 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Fugitive Extra Credit completes the Knolly Fugitive model. Knolly launched 21 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Knolly Fugitive Dawn Patrol 2020 is the most affordable bike of this model and has a price of 4580$. On the other hand, Knolly Fugitive LT Extra Credit 2020, is the most expensive and costs 5400$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2020 and its price was 5180$. If we compare this with the average Trail bike cost we notice that the price is 87.55% more expensive.
Overview of components
Fork
The RockShox Pike Ultimate is included from the factory. It has a travel distance of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Knolly Fugitive Extra Credit bike has the Trunnion mount model installed, and has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the Fugitive Extra Credit model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Knolly Fugitive Extra Credit has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Fugitive Extra Credit comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Knolly Fugitive Extra Credit comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
