Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona SuperLight Aluminum Butted 7046
Suspension Fork
Kona Carbon Race
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora
Cassette
Shimano HG200 11-32t 9spd
Crank
34/50t
Bottom Bracket
TH 7420
Chain
KMC Z99
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula
Rear Hub
Formula
Rims
Alex R500
Spokes
Sandvik 15g fr / 14g rr
Tires
Continental UltraSport II 700x28c
Brakes
Brakes
Tektro R359
Brake Levers
Shimano Sora
Disk Rotors
n/a
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.42/ACB
Seat
Saddle
Kona Road
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.51 mm | 1.54 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 262 mm | 262 mm | 264 mm | 264 mm |
| Front Center | 581 mm | 583 mm | 593 mm | 603 mm | 614 mm | 622 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 71 mm | 64 mm | 64 mm | 64 mm | 62 mm | 58 mm |
| Stack | 540 mm | 563 mm | 580 mm | 599 mm | 618 mm | 639 mm |
| Reach | 377 mm | 380 mm | 385 mm | 388 mm | 398 mm | 405 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm | 225 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 430 mm | 430 mm |
| Wheelbase | 996 mm | 998 mm | 1010 mm | 1019 mm | 1033 mm | 1042 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 74 mm | 72 mm | 72 mm |
| Standover Height | 728 mm | 756 mm | 777 mm | 795 mm | 817 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Esatto is part of the Kona Esatto model. 15 bikes variations carry this model name so far. Take a sneak peek at all Kona Esatto bikes models from 2016, by clicking here.
Model range prices
Kona Esatto 2016 is the most affordable bike of this model and has a price of 999$. On the other hand, Kona Esatto DDL 2016, is the most expensive and costs 2099$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Kona released this model in 2016, its price was 999$. Comparing the average cost of an Endurance bike to this one, you will see that Esatto price is 134.83% smaller.
Esatto components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Esatto are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Esatto has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
