Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona SuperLight Aluminum Butted 7046
Suspension Fork
Kona Carbon Road Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105
Shift Levers
Shimano RS505 Hydraulic
Cassette
Shimano 105 11-32t 11spd
Crank
34/50t
Bottom Bracket
Shimano R600
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Novatech Road 30 Disc Wheelset
Rear Hub
Novatech Road 30 Disc Wheelset
Rims
Novatech Road 30 Disc Wheelset
Spokes
Novatech Road 30 Disc Wheelset
Tires
Continental Gran Sport Race 700x28c
Brakes
Brakes
Shimano RS505 Hydraulic
Brake Levers
Shimano RS505 Hydraulic
Disk Rotors
Shimano 140mm
Cockpit
Stem
Kona Road Light
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.42/ACB
Seat
Saddle
Kona Road
Seatpost
Kona Road w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.51 mm | 1.54 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 262 mm | 262 mm | 264 mm | 264 mm |
| Front Center | 581 mm | 583 mm | 593 mm | 603 mm | 614 mm | 622 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 71 mm | 64 mm | 64 mm | 64 mm | 62 mm | 58 mm |
| Stack | 540 mm | 563 mm | 580 mm | 599 mm | 618 mm | 639 mm |
| Reach | 377 mm | 380 mm | 385 mm | 388 mm | 398 mm | 405 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm | 225 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 430 mm | 430 mm |
| Wheelbase | 996 mm | 998 mm | 1010 mm | 1019 mm | 1033 mm | 1042 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 74 mm | 72 mm | 72 mm |
| Standover Height | 728 mm | 756 mm | 777 mm | 795 mm | 817 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Esatto DDL belongs to the Kona Esatto model. 15 bikes variations carry this model name so far. Take a sneak peek at all Kona Esatto bikes models from 2016, by clicking here.
Model range prices
Kona Esatto 2016 is the most affordable bike of this model and has a price of 999$. On the other hand, Kona Esatto DDL 2016, is the most expensive and costs 2099$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2016 and its price was 2099$. Comparing this to the average Endurance bike price, we see that the price is 11.77% lower.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Kona Esatto DDL 2016, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Esatto DDL comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Esatto DDL comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
