Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox Recon Gold RL
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 6061 Aluminum Butted 100mm Travel
Suspension Fork
RockShox Recon Gold RL Solo Air 120mm Tapered
Rear Shock
RockShox Monarch RL
Drivetrain
Rear Derailleur
Shimano XT
Front Derailleur
n/a
Shift Levers
Shimano SLX
Cassette
Shimano SLX 11-42t 11spd
Crank
30t Narrow/wide
Bottom Bracket
Shimano PF92
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano Deore 100x15mm
Rear Hub
Shimano Deore 148x12mm
Rims
WTB STP i29 TCS
Spokes
Stainless Black 14g
Tires
Maxxis Ardent 29x2.25"
Brakes
Brakes
Shimano Hydraulic
Brake Levers
Shimano Hydraulic
Disk Rotors
Shimano RT30 180mm (Centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35 Riser
Grips
ODI Ruffian MX
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport SE (Volt Sport SE 250 size S)
Seatpost
KS Eten Integra 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 1.35 mm | 1.28 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 677 mm | 705 mm | 734 mm | 767 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 107 mm | 107 mm | 108 mm | 107 mm |
| Stack | 599 mm | 609 mm | 619 mm | 628 mm |
| Reach | 409 mm | 434 mm | 459 mm | 489 mm |
| Top Tube Length | 569 mm | 597 mm | 625 mm | 658 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1108 mm | 1137 mm | 1165 mm | 1199 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 754 mm | 754 mm | 764 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Hei Hei belongs to the Kona Hei model. Kona launched 58 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Kona Hei Hei 2017 is the most affordable bike of this model and has a price of 2499$. On the other hand, Kona Hei Hei Supreme 2017, is the most expensive and costs 7999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Kona Hei Hei price was 2499$. If we compare this with the average Crosscountry bike cost we notice that the price is 31.18% higher.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Gold RL model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Kona Hei Hei bike has the RockShox Monarch RL model installed, and has a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Hei Hei are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Hei Hei is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Kona Hei Hei bike has 4 sizes, in the range of 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Kona Hei Hei includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
