Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox Revelation RC
-
Groupset GX, SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 6061 Aluminum Butted 100mm Travel
Suspension Fork
RockShox Revelation RC DebonAir 120mm Tapered 110mm Spacing
Rear Shock
RockShox Monarch RL Solo Air
Drivetrain
Rear Derailleur
SRAM GX-Eagle
Front Derailleur
n/a
Shift Levers
SRAM SX-Eagle
Cassette
SRAM NX-Eagle 11-50t 12spd
Crank
SRAM NX-Eagle, 32t X-Sync Eagle
Bottom Bracket
SRAM DUB PF92
Chain
SRAM SX-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano 110x15mm (centerlock)
Rear Hub
Shimano 148x12mm (centerlock)
Rims
WTB ST i27 TCS
Spokes
Stainless Black 2.0
Tires
Maxxis Rekon EXO TR DUAL 29x2.25"
Brakes
Brakes
Shimano MT401 Hydraulic
Brake Levers
Shimano MT401 Hydraulic
Disk Rotors
Shimano RT54 180mm (centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport (Volt 250 size S)
Seatpost
Trans-X Dropper Internal 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.36 mm | 1.31 mm | 1.24 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 702 mm | 731 mm | 759 mm | 798 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 597 mm | 606 mm | 616 mm | 625 mm |
| Reach | 419 mm | 444 mm | 469 mm | 504 mm |
| Top Tube Length | 586 mm | 614 mm | 643 mm | 681 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° | 74.1 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1133 mm | 1162 mm | 1191 mm | 1230 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 755 mm | 756 mm | 765 mm | 787 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Hei Hei is a Kona Hei model. There are 58 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Kona Hei Hei 2020 is the most affordable bike of this model and has a price of 2599$. On the other hand, Kona Hei Hei CR/DL 2020, is the most expensive and costs 5999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2599$. Comparing this to the average Crosscountry bike price, we see that the price is 36.43% more expensive.
Hei Hei components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Kona Hei Hei bike has the RockShox Monarch RL Solo Air model installed, and has a travel of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Hei Hei 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Hei Hei has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Hei Hei. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
