Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Pike Ultimate
-
Groupset XX1, X0 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 120mm Travel
Suspension Fork
RockShox Pike Ultimate DebonAir 120mm Tapered 110mm Spacing
Rear Shock
RockShox Deluxe Ultimate
Drivetrain
Rear Derailleur
SRAM XX1-Eagle
Front Derailleur
n/a
Shift Levers
SRAM XO-Eagle
Cassette
SRAM XX1-Eagle 10-50t 12spd
Crank
SRAM Descendant DUB Carbon, 34t X-Sync Eagle
Bottom Bracket
SRAM DUB PF92
Chain
SRAM XX1-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
DT Swiss 370 110x15mm
Rear Hub
DT Swiss 370 148x12mm
Rims
WTB KOM Light i27 TCS
Spokes
Sandvik Stainless Black 2.0/1.8 Butted
Tires
Maxxis Rekon EXO TR 3C 29x2.25"
Brakes
Brakes
SRAM G2 RSC
Brake Levers
SRAM G2 RSC
Disk Rotors
SRAM Centerline 180mm
Cockpit
Stem
RaceFace Turbine R 35
Handlebar
RaceFace Next 35
Grips
Kona Key Grip
Headset
FSA No.57E
Seat
Saddle
WTB SL8 Pro
Seatpost
RockShox Reverb w/1x Remote Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.36 mm | 1.3 mm | 1.22 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 701 mm | 730 mm | 757 mm | 794 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 595 mm | 604 mm | 609 mm | 614 mm |
| Reach | 419 mm | 444 mm | 469 mm | 504 mm |
| Top Tube Length | 577 mm | 605 mm | 631 mm | 667 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1133 mm | 1162 mm | 1189 mm | 1226 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 745 mm | 745 mm | 745 mm | 745 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Hei Hei CR/DL is a Kona Hei model. There are 58 bikes that carry this model name. Take a sneak peek at all Kona Hei bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Kona Hei Hei 2020 has a starting price of 2599$. Kona Hei Hei CR/DL 2020 on the other hand is the most expensive at 5999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Kona Hei Hei CR/DL price was 5999$. Comparing the average cost of a Trail bike to this one, you will see that Hei Hei CR/DL price is 117.2% more expensive.
Overview of components
Fork
This bike has the RockShox Pike Ultimate fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is RockShox Deluxe Ultimate, with a travel distance of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Hei Hei CR/DL 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Hei Hei CR/DL is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Hei Hei CR/DL. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
