Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
50cm
147cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon
Suspension Fork
Kona Verso Full Carbon Flat Mount Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano GRX 400
Front Derailleur
Shimano GRX 400
Shift Levers
Shimano Tiagra
Cassette
Shimano Deore 11-36t 10spd
Crank
Shimano GRX 600 or Prowheel RPP-521, 30/46t
Bottom Bracket
Prowheel PF86
Chain
Shimano HG54
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm (centerlock)
Rear Hub
Formula 142x12mm (centerlock)
Rims
WTB KOM Team i25 TCS 2.0
Spokes
Stainless Black 14g
Tires
Maxxis Rambler EXO TR 700x45c
Brakes
Brakes
TRP HDC711C Mechanical / Hydraulic
Brake Levers
Shimano Tiagra
Disk Rotors
TRP TR160mm
Cockpit
Stem
Kona Road Deluxe
Handlebar
Kona Road
Grips
Velo Shock-Proof Bar Tape
Headset
FSA No.42ACB
Seat
Saddle
WTB Volt
Seatpost
Kona Deluxe Thumb w/Offset 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.53 mm | 1.57 mm | 1.61 mm | 1.67 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 288 mm | 288 mm | 290 mm |
| Front Center | 613 mm | 623 mm | 628 mm | 638 mm | 654 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 67 mm | 67 mm | 67 mm |
| Stack | 579 mm | 594 mm | 614 mm | 634 mm | 664 mm |
| Reach | 382 mm | 387 mm | 390 mm | 393 mm | 398 mm |
| Top Tube Length | 547 mm | 562 mm | 576 mm | 592 mm | 612 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 455 mm | 490 mm | 510 mm | 540 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 137.3 mm | 153.2 mm | 175.4 mm | 196.5 mm | 230.4 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1046 mm | 1056 mm | 1062 mm | 1072 mm | 1088 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 762 mm | 786 mm | 807 mm | 834 mm | 854 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
Model Overview
Libre CR is a Kona Libre model. Kona launched 15 bikes of this model so far. Take a sneak peek at all Kona Libre bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Kona Libre 2022 has a starting price of 2099$. Kona Libre CR/DL 2022 on the other hand is the most expensive at 3799$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2022 and its price was 2999$. If we compare this with the average Gravel bike cost we notice that the price is 21.81% more expensive.
Overview of components
Fork material
Libre CR has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Kona Libre CR 2022, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Libre CR is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Kona Libre CR bike has 5 sizes, in the range of 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, you can easily find one that suits you.
