Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 134mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 134mm Travel
Suspension Fork
RockShox Recon RL Motion Control Solo Air 140mm Tapered 110mm Spacing
Rear Shock
RockShox Deluxe Select Trunnion
Drivetrain
Rear Derailleur
Shimano Deore 11spd
Front Derailleur
n/a
Shift Levers
Shimano Deore 11spd
Cassette
Shimano Deore 11-50t 11spd
Crank
Shimano Deore, 30t
Bottom Bracket
Shimano Deore
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano 110x15mm
Rear Hub
Shimano 148x12mm
Rims
WTB ST i30 TCS 2.0
Spokes
Stainless Black 14g
Tires
Maxxis Dissector EXO TR DUAL 29x2.4" WT
Brakes
Brakes
Shimano MT201 Hydraulic
Brake Levers
Shimano MT201 Hydraulic
Disk Rotors
Shimano RT30 180mm (centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
Kona Trail
Seatpost
TranzX Dropper +RAD Internal 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.34 mm | 1.29 mm | 1.22 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 734 mm | 761 mm | 791 mm | 830 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 603 mm | 607 mm | 617 mm | 627 mm |
| Reach | 427 mm | 452 mm | 477 mm | 512 mm |
| Top Tube Length | 571 mm | 598 mm | 627 mm | 666 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.3 ° | 76.2 ° |
| Seat Tube Length | 385 mm | 410 mm | 450 mm | 485 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 93 mm | 98 mm | 109 mm | 120 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1161 mm | 1188 mm | 1218 mm | 1257 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 717 mm | 727 mm | 727 mm | 727 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Process 134 29 is a Kona Process 134 model. There are 38 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Kona Process 134 29 2021 is the cheapest bike model and costs 2499$. Kona Process 134 Supreme 2021 is the most expensive one and costs 10999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2021 and its price was 2499$. In conclusion, this bike price is 10.52% lower than the price of the average Trail bike.
Process 134 29 components
Fork
Kona Process 134 29 2021 bike is equipped with the RockShox Recon Silver RL fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the RockShox Deluxe Select Trunnion model, with a travel of 134mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Process 134 29 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Process 134 29 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Kona Process 134 29 bike has 4 sizes, in the range of 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Kona model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
