Kona Process 134 Supreme 2021
2021 Mountain
Estimate price |
10,999$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 134mm -
Fork RockShox Pike Ultimate
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Carbon 134mm Travel
Suspension Fork
RockShox Pike Ultimate RC2 charger 2 DebonAir 140mm Tapered 110mm Spacing
Rear Shock
RockShox Super Deluxe Ultimate Trunnion
Drivetrain
Rear Derailleur
SRAM XX1-Eagle AXS
Front Derailleur
n/a
Shift Levers
SRAM AXS Eagle Controller
Cassette
SRAM X01-Eagle 10-52t 12spd
Crank
SRAM X01 Eagle DUB, 32t X-Sync Eagle
Bottom Bracket
SRAM DUB PF92
Chain
SRAM X01-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Zipp 3Zero Moto Wheelset 110x15mm
Rear Hub
Zipp 3Zero Moto Wheelset 148x12mm
Rims
Zipp 3Zero Moto Wheelset
Spokes
Zipp 3Zero Moto Wheelset
Tires
Maxxis Dissector EXO TR 3C 29x2.4" WT
Brakes
Brakes
SRAM G2 Ultimate
Brake Levers
SRAM G2 Ultimate
Disk Rotors
SRAM Centerline 200mm
Cockpit
Stem
Truvativ Descendant 35
Handlebar
Truvativ Descendant DH Carbon 35
Grips
Kona Key Grip
Headset
FSA Orbit 1.5 E ZS
Seat
Saddle
WTB Volt Titanium
Seatpost
Rock Shox Reverb AXS w/AXS Controller Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.34 mm | 1.29 mm | 1.22 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 734 mm | 761 mm | 791 mm | 830 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 603 mm | 607 mm | 617 mm | 627 mm |
| Reach | 427 mm | 452 mm | 477 mm | 512 mm |
| Top Tube Length | 571 mm | 598 mm | 627 mm | 666 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.3 ° | 76.2 ° |
| Seat Tube Length | 385 mm | 410 mm | 450 mm | 485 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 93 mm | 98 mm | 109 mm | 120 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1161 mm | 1188 mm | 1218 mm | 1257 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 717 mm | 727 mm | 727 mm | 727 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Process 134 Supreme belongs to the Kona Process 134 model. Kona launched 38 bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Kona Process 134 27.5 2021 is the most economical model, with a starting price of 2499$. Kona Process 134 Supreme 2021 on the other hand costs 10999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Kona Process 134 Supreme price was 10999$. In conclusion, this bike price is 298.23% higher than the price of the average Trail bike.
Process 134 Supreme components
Fork
This bike has the RockShox Pike Ultimate fork installed. The fork’s travel is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Ultimate Trunnion model, with a travel of 134mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on Process 134 Supreme are the 29″ carbon type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Process 134 Supreme comes in 4 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Process 134 Supreme. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
