Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 134mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 134mm Travel
Suspension Fork
RockShox Recon RL Motion Control Solo Air 140mm Tapered 110mm Spacing
Rear Shock
RockShox Deluxe Select Trunnion
Drivetrain
Rear Derailleur
Shimano Deore 11spd
Front Derailleur
n/a
Shift Levers
Shimano Deore 11spd
Cassette
Shimano Deore 11-50t 11spd
Crank
Shimano Deore, 30t
Bottom Bracket
Shimano Deore
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano 110x15mm
Rear Hub
Shimano 148x12mm
Rims
WTB ST i30 TCS 2.0
Spokes
Stainless Black 14g
Tires
Maxxis Dissector EXO TR DUAL 27.5x2.4" WT
Brakes
Brakes
Shimano MT201 Hydraulic
Brake Levers
Shimano MT201 Hydraulic
Disk Rotors
Shimano RT30 180mm (centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
Kona Trail
Seatpost
TranzX Dropper +RAD Internal 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.41 mm | 1.35 mm | 1.3 mm | 1.23 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 706 mm | 735 mm | 765 mm | 794 mm | 834 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 107 mm | 108 mm | 107 mm | 108 mm | 108 mm |
| Stack | 579 mm | 589 mm | 599 mm | 609 mm | 620 mm |
| Reach | 394 mm | 419 mm | 444 mm | 469 mm | 504 mm |
| Top Tube Length | 531 mm | 561 mm | 590 mm | 619 mm | 658 mm |
| Seat Tube Angle | 76.8 ° | 76.6 ° | 76.5 ° | 76.3 ° | 76.2 ° |
| Seat Tube Length | 360 mm | 385 mm | 410 mm | 450 mm | 485 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 116 mm | 127 mm | 138 mm | 149 mm | 160 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1125 mm | 1154 mm | 1184 mm | 1213 mm | 1253 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 668 mm | 681 mm | 706 mm | 706 mm | 705 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Process 134 27.5 belongs to the Kona Process 134 model. 38 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Kona Process 134 29 2021 has a starting price of 2499$. Kona Process 134 Supreme 2021 on the other hand is the most expensive at 10999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Kona Process 134 27.5 price was 2499$. Comparing this to the average Trail bike price, we see that the price is 10.52% lower.
Process 134 27.5 components
Fork
Kona Process 134 27.5 2021 bike is equipped with the RockShox Recon Silver RL fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Process 134 27.5 has a rear shock with a travel of 134mm. The model RockShox Deluxe Select Trunnion is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Process 134 27.5 bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Process 134 27.5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Process 134 27.5 comes in 5 sizes, that range from 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Kona Process 134 27.5 includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
