Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork SunTour Zeron
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano 504Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Suntour Zeron35 140mm Tapered 110 Spacing
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
n/a
Shift Levers
Shimano Deore
Cassette
Shimano Deore 11-46t 10spd
Crank
Shimano E8000, 34t
Bottom Bracket
n/a
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano 110x15mm
Rear Hub
Shimano 148x12mm
Rims
WTB ST i35 TCS 2.0
Spokes
Stainless Black 14g
Tires
Maxxis Minion DHR II EXO TR DUAL 29x2.4" WT
Brakes
Brakes
Shimano MT410 Hydrualic
Brake Levers
Shimano MT410 Hydrualic
Disk Rotors
Shimano RT30 203mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
WTB Volt
Seatpost
TranzX Dropper Internal 31.6mm
Motor & Battery
Motor
Shimano E7000 20MPH
Battery
Shimano 504Wh
Remote
Shimano SC-E7000 Display
Charger
Shimano STEPS 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.44 mm | 1.39 mm | 1.31 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 744 mm | 771 mm | 800 mm | 839 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 647 mm | 652 mm | 661 mm | 670 mm |
| Reach | 427 mm | 452 mm | 477 mm | 512 mm |
| Top Tube Length | 587 mm | 613 mm | 641 mm | 678 mm |
| Seat Tube Angle | 76.1 ° | 76.1 ° | 76.1 ° | 76.1 ° |
| Seat Tube Length | 385 mm | 410 mm | 450 mm | 485 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 115 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1177 mm | 1204 mm | 1233 mm | 1272 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 738 mm | 738 mm | 738 mm | 738 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Remote belongs to the Kona E Remote model. There are 16 e-bikes that carry this model name. Take a sneak peek at all Kona E Remote e-bikes models from 2022, by clicking here.
Model range prices
Kona Remote 2022 is the cheapest e-bike model and costs 4699$. Kona Remote 160 2022 is the most expensive one and costs 6299$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Utility e-bikes
If you want an acceptable Utility e-bike you should know that the average price is 3636$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Utility e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Kona Remote price was 4699$. Comparing the average cost of an Utility e-bike to this one, you will see that Remote price is 29.24% more expensive.
Overview of components
Fork
The fork installed on this bike is the SunTour Zeron model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Remote 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Remote has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Kona Remote comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
