Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Rival 1, SRAM -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
48cm
147cm - 160cm
50cm
152cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Butted Cromoly
Suspension Fork
Kona Project Two Cromoly Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Rival 1
Front Derailleur
n/a
Shift Levers
SRAM Rival 1
Cassette
SRAM PG1130 11-42t 11spd
Crank
SRAM S350, 40t X-Sync
Bottom Bracket
SRAM GXP 68mm
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB Asym i23 TCS
Spokes
Stainless Black 14g
Tires
WTB Horizon Road Plus TCS 650x47c
Brakes
Brakes
TRP Spyre C Flat Mount
Brake Levers
SRAM Rival 1
Disk Rotors
TRP 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA TH848
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 272 mm | 272 mm |
| Front Center | 587 mm | 599 mm | 606 mm | 618 mm | 624 mm | 639 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 69 mm | 66 mm | 66 mm | 62 mm | 63 mm |
| Stack | 525 mm | 545 mm | 565 mm | 585 mm | 605 mm | 625 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 387 mm | 395 mm |
| Top Tube Length | 510 mm | 526 mm | 541 mm | 558 mm | 574 mm | 594 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 83 mm | 104 mm | 126 mm | 147 mm | 168 mm | 189 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1006 mm | 1018 mm | 1026 mm | 1038 mm | 1045 mm | 1059 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 725 mm | 745 mm | 765 mm | 785 mm | 805 mm | 825 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 160 cm | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
Model Overview
Rove ST completes the Kona Rove model. Kona released 49 bikes variations of this model so far. Take a sneak peek at all Kona Rove bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Kona Rove 2019 has a starting price of 849$. Kona Rove LTD 2019 on the other hand is the most expensive at 3599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Kona Rove ST price was 1599$. Comparing this to the average Gravel bike price, we see that the price is 53.97% lower.
Rove ST components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Kona Rove ST 2019, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Rove ST has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 6 sizes. They vary from 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, you can easily find one that suits you.
