Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Recon Gold RL
-
Groupset Deore, Race Face -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon Gold RL SoloAir, Boost
Rear Shock
RockShox Deluxe RL DebonAir, Trunnion
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
N/A
Shift Levers
Shimano Deore, 10-speed
Cassette
Shimano Deore, 11-42 tooth, 10-speed
Crank
Race Face Aeffect
Bottom Bracket
Shimano PF92
Chain
Shimano HG54
Chain Guide
N/A
Pedals
Kona JS2
Wheels
Front Hub
Shimano Deore, Boost front and rear
Rear Hub
Shimano Deore, Boost front and rear
Rims
WTB STP i29 TCS
Spokes
Sandvik Stainless 14g, black
Tires
Front: Maxxis Minion DHF, 2.3" TR Dual, Rear: Maxxis Tomahawk, 2.3" TR Dual
Brakes
Brakes
Shimano with 180mm front/160mm rear Centerlock rotors
Brake Levers
Shimano
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport SE (Volt 250 Sport SE size S)
Seatpost
Trans-X Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.32 mm | 1.25 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Stack | 613 mm | 622 mm | 631 mm | 641 mm |
| Reach | 429 mm | 454 mm | 479 mm | 514 mm |
| Top Tube Length | 554 mm | 581 mm | 609 mm | 646 mm |
| Seat Tube Angle | 78.4 ° | 78.4 ° | 78.3 ° | 78.3 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1147 mm | 1176 mm | 1205 mm | 1244 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 730 mm | 767 mm | 767 mm | 787 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Satori belongs to the Kona Satori model. Kona launched 7 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Kona Satori 2018 is the cheapest bike model and costs 2699$. Kona Satori DL 2018 is the most expensive one and costs 3499$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Kona Satori price was 2699$. In conclusion, this bike price is 2.33% lower than the price of the average Trail bike.
Satori components
Fork
Kona Satori 2018 bike is equipped with the RockShox Recon Gold RL fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the RockShox Deluxe RL DebonAir rear shock model, which has a travel of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Satori 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Satori comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Kona model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
