Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Revelation RC
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC SoloAir, Boost
Rear Shock
RockShox Deluxe RL DebonAir, Trunnion
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle, 10-50 tooth, 12-speed
Crank
SRAM Descendant 6K
Bottom Bracket
SRAM GXP PF92
Chain
SRAM GX Eagle
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Formula, Boost front and rear
Rear Hub
Formula, Boost front and rear
Rims
WTB STP i29 TCS
Spokes
Stainless 15g, black
Tires
Front: Maxxis Minion DHF, 2.3" TR Dual, Rear: Maxxis Tomahawk, 2.3" TR Dual
Brakes
Brakes
SRAM Guide R with 180mm front/160mm rear Centerline rotors
Brake Levers
SRAM Guide R
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key
Headset
FSA No.57E
Seat
Saddle
WTB Volt Comp (Volt 250 Comp size S)
Seatpost
RockShox Reverb with plunger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.32 mm | 1.25 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Stack | 613 mm | 622 mm | 631 mm | 641 mm |
| Reach | 429 mm | 454 mm | 479 mm | 514 mm |
| Top Tube Length | 554 mm | 581 mm | 609 mm | 646 mm |
| Seat Tube Angle | 78.4 ° | 78.4 ° | 78.3 ° | 78.3 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1147 mm | 1176 mm | 1205 mm | 1244 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 730 mm | 767 mm | 767 mm | 787 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Satori DL completes the Kona Satori model. Kona released 7 bikes variations of this model so far. Take a sneak peek at all Kona Satori bikes models from 2018, by clicking here.
Model range prices
Kona Satori 2018 is the most affordable bike of this model and has a price of 2699$. On the other hand, Kona Satori DL 2018, is the most expensive and costs 3499$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3499$. In conclusion, this bike price is 26.68% higher than the price of the average Trail bike.
Overview of components
Fork
This bike has the RockShox Revelation RC fork installed. The fork’s travel is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Satori DL has a rear shock with a travel of 130mm. The model RockShox Deluxe RL DebonAir is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The Satori DL 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Satori DL has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Kona model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
