KTM MACINA TEAM 792 LFC 2022
2022 E-bike
Estimate price |
5,160$
Weight | 24.3 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR 34
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTUBE 750Wh hor. smart system -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina MTB 29" Alloy6061; PT750Wh Bosch Gen.4 / M-2706
Suspension Fork
Suntour XCR 34 Air 29" LOR 120mm 15x110 taper
Drivetrain
Rear Derailleur
Shimano Deore M5130-10 LG shadow+
Shift Levers
Shimano Deore M5130-10 LG display
Cassette
Shimano LG600-10 / 11-43
Crank
KTM COMP ISIS 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
Shimano LG500
Wheels
Rims
KTM Line - Shimano MT410B CL 32H 110-15TA / Ryde Rival30 32H 622x30C / DT Champion 2.0 black
Brakes
Brakes
Tektro HD-M535 4-Piston
Disk Rotors
Tektro TR-45 2.3mm CL 180 / TR-45 2.3mm CL 180
Cockpit
Stem
KTM Line adjust. 0-60° internal
Handlebar
KTM Comp rizer15 700mm
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
Selle Royal Lookin Athletic
Seatpost
KTM Team 30.9/400
Motor & Battery
Motor
Bosch PERFORMANCE CX Gen.4 smart system - 25km/h / 85Nm
Battery
Bosch PowerTUBE 750Wh hor. smart system
Remote
Bosch KIOX TFT Display smart system
Charger
Bosch STANDARD Charger 4A smart system
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.51 mm | 1.48 mm | 1.46 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 294 mm |
| Front Center | 677 mm | 688 mm | 709 mm | 734 mm |
| Rake | 46 mm | 51 mm | 52 mm | 60 mm |
| Trail | 102 mm | 89 mm | 88 mm | 79 mm |
| Stack | 614 mm | 621 mm | 632 mm | 645 mm |
| Reach | 396 mm | 410 mm | 426 mm | 443 mm |
| Top Tube Length | 585 mm | 601 mm | 621 mm | 641 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm | 570 mm |
| Head Tube Angle | 68 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 120 mm | 125 mm | 137 mm | 150 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1141 mm | 1152 mm | 1173 mm | 1193 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 80 mm |
| Standover Height | 802 mm | 803 mm | 830 mm | 856 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
MACINA TEAM 792 LFC is a Ktm E Macina Team model. 39 e-bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
KTM MACINA TEAM 693 2022 is the most affordable e-bike of this model and has a price of 3928$. On the other hand, KTM MACINA TEAM 791 2022, is the most expensive and costs 5414$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, KTM MACINA TEAM 792 LFC price was 4777$. Comparing the average cost of a Trail e-bike to this one, you will see that MACINA TEAM 792 LFC price is 41.96% more expensive.
Average weight for Trail e-bikes
Trail e-bikes have an average weight of 23.7 kg (52.25 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 24.3 kg (53.57 lbs), KTM e-bike is slightly heavier than average. In other words, this model is 2.53% heavier than the average Trail e-bike.
Overview of components
Fork
The fork installed on this bike is the Suntour XCR 34 model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the MACINA TEAM 792 LFC model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
