Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor Yamaha 250W 70Nm mid-drive -
Battery EnergyPak 500 -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX aluminum, Overdrive 1½ - 1?" head tube, integrated KSA18 kickstand mount
Suspension Fork
SR Suntour NEX DS 63mm travel
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Alivio, 9-speed
Front Derailleur
n/a
Shift Levers
Shimano Altus
Cassette
Shimano CS-HG200, 11-36T, 9-Speed
Crank
Forged Alloy minimal Q-factor, 42T
Bottom Bracket
n/a
Chain
KMC e.9 Sport, e-bike optimized
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Rear Hub
Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Rims
Giant eX 2, Tubeless Ready, 622x21 aluminium
Spokes
Stainless steel
Tires
Giant Crosscut Gravel 2, 700x50c, Tubeless Ready
Brakes
Brakes
Tektro HD-M276, hydraulic disc, 180mm [F], 160mm [R]
Brake Levers
Tektro HD-M276
Cockpit
Stem
Giant Contour TDS 816-8FOV (XS/S/M:80mm L 100mm)
Handlebar
Giant Connect Riser 31.8x620mm (XS/S), 690mm(M/L)
Grips
Liv Contact Ergo Max Plus
Seat
Saddle
Liv Sport Comfort
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Sport, 70Nm, powered by Yamaha
Battery
EnergyPak 500
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.6 mm | 1.58 mm |
| Front Center | 637 mm | 652 mm | 667 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 89 mm | 89 mm |
| Stack | 618 mm | 627 mm | 637 mm |
| Reach | 381 mm | 393 mm | 404 mm |
| Top Tube Length | 552 mm | 572 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 385 mm | 435 mm | 485 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1102 mm | 1117 mm | 1132 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 615 mm | 598 mm | 586 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Amiti E+ 3 completes the Liv E Amiti model. 20 e-bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Liv Amiti E+ 3 2023 is the cheapest e-bike model and costs 2819$. Liv Amiti E+ Pro 2023 is the most expensive one and costs 3976$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid e-bikes
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Liv Amiti E+ 3 price was 2819$. Doing a quick comparison, we notice that Amiti E+ 3 price is 13.67% more expensive than the average cost of a Hybrid e-bike.
Overview of components
Fork
Liv Amiti E+ 3 2023 e-bike is equipped with the Suntour NEX fork, and has 63mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Liv Amiti E+ 3 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Amiti E+ 3 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Amiti E+ 3 comes in 3 sizes, that range from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, you won’t have a problem finding one that suits you.
