Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Motor Yamaha 250W 85Nm mid-drive -
Battery EnergyPak Smart 800, EnergyPak Plus 250 range extender compatible (exclude XS size) -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX aluminum, Overdrive 1.8" - 1.5" head tube, integrated battery, integrated KSA40 kickstand mount
Suspension Fork
SR Suntour XCR34 Air Boost, 100mm travel, Hydraulic Lockout, 15x110mm AH Axle
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore LinkGlide, 10-speed, Shadow+
Front Derailleur
n/a
Shift Levers
Shimano Deore LinkGlide
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Crank
Forged Alloy Direct spider/chainguard 46T Steel narrow/wide chainring
Bottom Bracket
n/a
Chain
Shimano, LinkGlide, CN-LG500
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker, [F] 110x15 [R] 1142x12
Rear Hub
Giant eTracker, [F] 110x15 [R] 1142x12
Rims
eX25, Tubeless Ready, 622x25 Aluminium
Spokes
Stainless steel, e-bike optimized
Tires
Crosscut Gravel 1, 700x57, Foldable, Tubeless Ready
Brakes
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M745
Cockpit
Stem
Giant Contour EVO integrated 16? (XS/S/M:80mm L 100mm)
Handlebar
Giant Contour Comfort Riser 31.8x 690mm
Grips
Liv Contact Ergo Max Plus
Seat
Saddle
Liv Sport Comfort
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Pro2 85Nm, powered by Yamaha
Battery
EnergyPak Smart 800, EnergyPak Plus 250 range extender compatible (exclude XS size)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.69 mm | 1.72 mm |
| Front Center | 685 mm | 684 mm | 693 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 88 mm | 84 mm | 84 mm |
| Stack | 657 mm | 669 mm | 683 mm |
| Reach | 395 mm | 395 mm | 398 mm |
| Top Tube Length | 572 mm | 582 mm | 602 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 410 mm | 435 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 135 mm | 145 mm | 160 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1146 mm | 1145 mm | 1154 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 673 mm | 681 mm | 660 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Amiti E+ Pro completes the Liv E Amiti model. Liv launched 20 e-bikes of this model so far. You can easily view all of the Liv E Amiti e-bikes models from 2023, here.
Model range prices
The most economical model, the Liv Amiti E+ 3 2023 has a starting price of 2819$. Liv Amiti E+ Pro 2023 on the other hand is the most expensive at 3976$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3976$. Doing a quick comparison, we notice that Amiti E+ Pro price is 60.32% more expensive than the average cost of a Hybrid e-bike.
Amiti E+ Pro components
Fork
Liv Amiti E+ Pro 2023 e-bike is equipped with the Suntour XCR Air fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on Amiti E+ Pro are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Liv Amiti E+ Pro e-bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
