Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
153cm - 162cm
SM
158cm - 169cm
MD
165cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminium, 12x142mm thru-axle, disc
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 GS
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 ST-R7025
Cassette
Shimano 105, 11-speed, 11x34
Crank
Shimano FC-RS510, 34/50 XS:165mm, S:170mm, M:170mm
Bottom Bracket
Cartridge
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant P-R2 Disc wheelset
Rear Hub
Giant P-R2 Disc wheelset
Rims
Giant P-R2 Disc wheelset
Spokes
Giant P-R2 Disc wheelset
Tires
Giant Gavia Fondo 2, 700x32c, tubeless
Brakes
Brakes
Shimano 105 hydraulic, Shimano rotors [F]160mm, [R]160mm
Brake Levers
Shimano 105
Cockpit
Stem
Giant Contact XS:70mm, S:80mm, M:90mm
Handlebar
Liv D-Fuse SL, 31.8mm XS:38cm, S:40cm, M:40cm
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant D-Fuse, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.53 mm | 1.57 mm |
| Bottom Bracket Height | 256 mm | 256 mm | 256 mm |
| Front Center | 590 mm | 592 mm | 597 mm |
| Rake | 53 mm | 53 mm | 53 mm |
| Trail | 69.5 mm | 62.9 mm | 59.6 mm |
| Stack | 531 mm | 554 mm | 575 mm |
| Reach | 359 mm | 362 mm | 366 mm |
| Top Tube Length | 508 mm | 518 mm | 533 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 410 mm | 445 mm | 480 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 118 mm | 138 mm | 158 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm |
| Wheelbase | 992 mm | 994 mm | 999 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm |
| Standover Height | 674 mm | 702 mm | 729 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 158 cm | 165 cm |
| Rider Max Height | 162 cm | 169 cm | 174 cm |
Model Overview
Avail AR 1 is part of the Liv Avail Ar model. There are 13 bikes that carry this model name. Take a sneak peek at all Liv Avail Ar bikes models from 2022, by clicking here.
Model range prices
Liv Avail AR 4 2022 is the cheapest bike model and costs 891$. Liv Avail AR 1 2022 is the most expensive one and costs 1528$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 1528$. If we compare this with the average Endurance bike cost we notice that the price is 53.53% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Avail AR 1 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 153 cm – 174 cm (5.02 ft – 5.71 ft). In conclusion, finding one for you shouldn’t be a problem.
