Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
153cm - 162cm
SM
158cm - 169cm
MD
165cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminium, 12x142mm thru-axle, disc
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris
Cassette
Shimano CS-HG50, 8-speed, 11x34
Crank
FSA Tempo, 34/50 XS:165mm, S:170mm, M:170mm
Bottom Bracket
Cartridge
Chain
KMC Z83
Pedals
N/A
Wheels
Front Hub
Giant S-R2 Disc wheelset
Rear Hub
Giant S-R2 Disc wheelset
Rims
Giant S-R2 Disc wheelset
Spokes
Giant S-R2 Disc wheelset
Tires
Giant S-R3 AC, 700x32c
Brakes
Brakes
Tektro MD-C550 mechanical, Shimano rotors [F]160mm, [R]160mm
Brake Levers
Shimano Claris
Cockpit
Stem
Giant Sport XS:70mm, S:80mm, M:90mm
Handlebar
Liv Connect, 31.8mm XS:38cm, S:40cm, M:40cm
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant D-Fuse, alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.53 mm | 1.57 mm |
| Bottom Bracket Height | 256 mm | 256 mm | 256 mm |
| Front Center | 590 mm | 592 mm | 597 mm |
| Rake | 53 mm | 53 mm | 53 mm |
| Trail | 69.5 mm | 62.9 mm | 59.6 mm |
| Stack | 531 mm | 554 mm | 575 mm |
| Reach | 359 mm | 362 mm | 366 mm |
| Top Tube Length | 508 mm | 518 mm | 533 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 410 mm | 445 mm | 480 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 118 mm | 138 mm | 158 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm |
| Wheelbase | 992 mm | 994 mm | 999 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm |
| Standover Height | 674 mm | 702 mm | 729 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 158 cm | 165 cm |
| Rider Max Height | 162 cm | 169 cm | 174 cm |
Model Overview
Avail AR 4 is part of the Liv Avail Ar model. Liv released 13 bikes variations of this model so far. Take a sneak peek at all Liv Avail Ar bikes models from 2022, by clicking here.
Model range prices
Liv Avail AR 4 2022 is the most economical model, with a starting price of 891$. Liv Avail AR 1 2022 on the other hand costs 1528$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 891$. In conclusion, this bike price is 163.3% smaller than the price of the average Endurance bike.
Avail AR 4 components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Avail AR 4 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Avail AR 4 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Avail AR 4 comes in 3 sizes, that range from 153 cm – 174 cm (5.02 ft – 5.71 ft). In conclusion, finding one for you shouldn’t be a problem.
