Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
153cm - 162cm
SM
158cm - 169cm
MD
165cm - 174cm
LG
171cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade aluminium, 12x142mm thru-axle, disc
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora
Cassette
Shimano CS-HG400, 9-speed, 11x34
Crank
Shimano Sora, 34/50 XS:165mm, S:170mm, M:170mm, L:172.5mm
Bottom Bracket
Cartridge
Chain
KMC X9
Pedals
N/A
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant S-R2 Disc wheelset
Spokes
Sapim
Tires
Giant S-R3 AC, 700x32c
Brakes
Brakes
Tektro MD-C550 mechanical, Giant MPH Rotors [F]160mm, [R]160mm
Brake Levers
Shimano Sora
Cockpit
Stem
Giant Sport XS:70mm, S:80mm, M:90mm, L:90mm
Handlebar
Liv Connect, 31.8mm XS:38cm, S:40cm, M:40cm, L:42cm
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant D-Fuse, alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.52 mm | 1.56 mm | 1.569 mm |
| Bottom Bracket Height | 256 mm | 256 mm | 256 mm | 256 mm |
| Front Center | 590 mm | 592 mm | 597 mm | 613 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 69.5 mm | 62.9 mm | 59.6 mm | 59.6 mm |
| Stack | 538 mm | 561 mm | 582 mm | 601 mm |
| Reach | 366 mm | 369 mm | 373 mm | 383 mm |
| Top Tube Length | 515 mm | 525 mm | 540 mm | 555 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 445 mm | 480 mm | 515 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 118 mm | 138 mm | 158 mm | 178 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 999 mm | 1001 mm | 1006 mm | 1022 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 681 mm | 709 mm | 736 mm | 766 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 158 cm | 165 cm | 171 cm |
| Rider Max Height | 162 cm | 169 cm | 174 cm | 182 cm |
Model Overview
Avail AR 3 completes the Liv Avail Ar model. Liv released 16 bikes variations of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
The most economical model, the Liv Avail AR 4 2024 has a starting price of 1011$. Liv Avail AR 1 2024 on the other hand is the most expensive at 1879$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2024 and its price was 1155$. Comparing this to the average Endurance bike price, we see that the price is 103.12% lower.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Liv Avail AR 3 2024, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Avail AR 3 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Liv Avail AR 3 bike has 4 sizes, in the range of 153 cm – 182 cm (5.02 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
