Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox 30 Silver TK
-
Groupset Deore, Alivio -
Suspension Full -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, 120mm FlexPoint suspension
Suspension Fork
RockShox 30 Gold Solo Air, OverDrive, 120mm travel
Rear Shock
RockShox Monarch R
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Deore
Shift Levers
Shimano Alivio
Cassette
Shimano HG400 12x36, 9-speed
Crank
FSA Comet, 24/38
Bottom Bracket
FSA, Press fit
Chain
KMC X9
Pedals
N/A
Wheels
Front Hub
Giant Tracker Sport Disc, 32h, QR
Rear Hub
Giant Tracker Sport Disc, 32h, QR
Rims
Giant Alloy, Double wall
Spokes
Stainless Steel, 14g
Tires
Maxxis Ardent, 27.5x2.25, Wire Bead
Brakes
Brakes
Shimano M315, hydraulic disc, [F] 180mm [R] 160mm
Brake Levers
Shimano M315
Cockpit
Stem
Giant Sport
Handlebar
Giant Connect Trail, 31.8mm
Seat
Saddle
Liv Connect Upright
Seatpost
Giant Sport, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.36 mm | 1.36 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 655 mm | 675 mm | 691 mm | 702 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 562 mm | 567 mm | 576 mm | 585 mm |
| Reach | 394 mm | 412 mm | 424 mm | 431 mm |
| Top Tube Length | 554 mm | 574 mm | 594 mm | 604 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 370 mm | 390 mm | 440 mm | 490 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1093 mm | 1113 mm | 1129 mm | 1140 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 696 mm | 697 mm | 725 mm | 761 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Embolden 2 completes the Liv Embolden model. There are 14 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Liv Embolden 2 2017 is the cheapest bike model and costs 1365$. Liv Embolden 1 2017 is the most expensive one and costs 2100$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Liv Embolden 2 price was 1365$. Comparing the average cost of a Trail bike to this one, you will see that Embolden 2 price is 102.34% lower.
Overview of components
Fork
The Embolden 2 comes factory-installed with the RockShox 30 Silver TK fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Embolden 2 has a rear shock with a travel of 120mm. The model RockShox Monarch R is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
As for the wheels, Liv Embolden 2 2017, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Embolden 2 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Embolden 2 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
