Liv Embolden E+ 2, 625 2023
2023 E-bike
Estimate price |
4,400$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 125mm -
Fork Suntour XCR
-
Groupset Deore, FSA -
Suspension Full -
Motor Yamaha 250W 75Nm mid-drive -
Battery EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 163cm
SM
155cm - 172cm
MD
164cm - 175cm
LG
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
Suspension Fork
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
Rear Shock
SR Suntour Raidon R, 190x45mm, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
Front Derailleur
MRP HD2 co-moulded chain guide
Shift Levers
Shimano Deore LinkGlide
Cassette
Shimano CS-LG400-10, 11-43T, 10-speed LinkGlide
Crank
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
Bottom Bracket
n/a
Chain
Shimano, LinkGlide, CN-LG500
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Rear Hub
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Rims
AM30, 27.5" (XS), 29"(S, M, L), Tubeless ready, 30mm inner width
Spokes
Stainless Steel
Tires
Maxxis Minion DHF 27x2.5"(XS), 29X2.50"(S, M, L) Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 27.5x2.4"(XS), 29X2.40"(S, M, L) Foldable WT, TLR, EXO, 60TPI [R]
Brakes
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M745 Orion
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x750mm (XS-S), 780mm (M-L)
Grips
Liv Tactal Pro Single Lock-On Grips
Seat
Saddle
Liv sylvia E
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Sport 2, 75Nm, powered by Yamaha
Battery
EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.46 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 335 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 734 mm | 734 mm | 750 mm | 772 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 121 mm | 121 mm | 121 mm | 121 mm |
| Stack | 598 mm | 618 mm | 627 mm | 636 mm |
| Reach | 423 mm | 422 mm | 434 mm | 452 mm |
| Top Tube Length | 562 mm | 572 mm | 592 mm | 612 mm |
| Seat Tube Angle | 77 ° | 76.5 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 395 mm | 425 mm | 455 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1198 mm | 1196 mm | 1212 mm | 1234 mm |
| Bottom Bracket Drop | 20 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 687 mm | 707 mm | 732 mm | 757 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 155 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 172 cm | 175 cm | 181 cm |
About this model
Embolden E+ 2, 625 belongs to the Liv E Embolden model. Liv released 21 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Liv Embolden E+ EX 2023 is the most affordable e-bike of this model and has a price of 3904$. On the other hand, Liv Embolden E+ 1, Pro 2023, is the most expensive and costs 5300$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4400$. In conclusion, this e-bike price is 30.76% more expensive than the price of the average Trail e-bike.
Embolden E+ 2, 625 components
Fork
The fork installed on this bike is the Suntour XCR model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Embolden E+ 2, 625 has a rear shock with a travel of 125mm. The model SR Suntour Raidon R is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Embolden E+ 2, 625 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Embolden E+ 2, 625 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 181 cm (4.92 ft – 5.94 ft). In conclusion, finding one for you shouldn’t be a problem.
