Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork SunTour AION
-
Groupset SLX, Deore -
Suspension Full -
Motor Yamaha mid-drive -
Battery Giant EnergyPak 500, 36V 13.8Ah integrated Lithium-Ion -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Aion 35 Air LO-R 27.5+, lockout, Boost 110x15mm Quick-Loc thru-axle
Rear Shock
FOX Float DPS Performance, EVOL large volume sleeve, 3-position lever, 185x52.5mm, Trunnion mount, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore SLX, 10-speed, Shadow+
Shift Levers
Shimano Deore
Cassette
Shimano HG50-10, 11-36 tooth, 10-speed
Crank
Praxis e-Cadet+ custom forged
Chain
KMC e.10 Sport, e-bike optimized
Chain Guide
MRP 1X CS custom
Pedals
None
Wheels
Front Hub
Giant eTracker, sealed cartridge bearing, 6-bolt, e-bike optimized
Rear Hub
Giant eTracker, sealed cartridge bearing, 6-bolt, e-bike optimized
Rims
Giant AM 27.5+, tubeless ready, 35mm inner width, e-bike optimized
Spokes
Front: Sapim E-Lite, e-bike optimized, Rear: Sapim Race, e-bike optimized
Tires
Front: Maxxis Minion DHF 27.5x2.6", foldable, tubeless, EXO, dual compound, Rear: Maxxis Rekon 27.5x2.6", foldable, tubeless, EXO, dual compound
Brakes
Brakes
Tektro HD-M745 Orion, 4-piston hydraulic disc, 203mm rotors
Brake Levers
Tektro HD-M745 Orion
Cockpit
Stem
Giant Contact SL 35
Handlebar
Giant Contact SL 35 Trail
Headset
OverDrive, integrated
Seat
Saddle
Liv Contact, upright
Seatpost
Giant Contact Switch dropper with under bar lever
Motor & Battery
Motor
Giant SyncDrive Pro, 360% tuneable support, powered by YAMAHA
Battery
Giant EnergyPak 500, 36V 13.8Ah integrated Lithium-Ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.37 mm | 1.35 mm |
| Bottom Bracket Height | 370 mm | 370 mm | 370 mm | 370 mm |
| Front Center | 699 mm | 715 mm | 731 mm | 759 mm |
| Rake | 34 mm | 34 mm | 35 mm | 35 mm |
| Trail | 118 mm | 118 mm | 116 mm | 116 mm |
| Stack | 576 mm | 581 mm | 585 mm | 604 mm |
| Reach | 401 mm | 415 mm | 428 mm | 448 mm |
| Top Tube Length | 562 mm | 577 mm | 592 mm | 617 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 406 mm | 445 mm | 482 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 125 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1166 mm | 1182 mm | 1198 mm | 1226 mm |
| Bottom Bracket Drop | -15 mm | -15 mm | -15 mm | -15 mm |
| Standover Height | 704 mm | 722 mm | 750 mm | 778 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Intrigue E+ 2 Pro is a Liv E Intrigue model. Liv released 24 e-bikes variations of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Liv Intrigue E+ 1 Pro 2019 is the cheapest e-bike model and costs 4600$. Liv Intrigue E+ 1 Pro 2019 is the most expensive one and costs 4830$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Intrigue E+ 2 Pro components
Fork
This e-bike has the SunTour AION fork installed. The fork’s travel is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Intrigue E+ 2 Pro has a rear shock with a travel of 140mm. The model FOX Float DPS Performance is the one installed in this e-bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the Intrigue E+ 2 Pro e-bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Intrigue E+ 2 Pro is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Intrigue E+ 2 Pro comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Liv Intrigue E+ 2 Pro comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
