Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Revelation RC
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite w/ ALUXX SL rear triangle, Advanced Forged composite upper rocker, 120mm Maestro suspension
Suspension Fork
RockShox Revelation RL Solo-Air, Maxle Stealth, Boost, OverDrive, 120mm travel
Rear Shock
RockShox Deluxe RT, Trunnion mount
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
SRAM GX
Cassette
SRAM XG-1150 10-42, 11-speed
Crank
SRAM GX, 30T
Bottom Bracket
SRAM GXP, Press fit
Chain
KMC X11 EL
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Rear Hub
Giant Performance Tracker Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Rims
Giant XC-1
Spokes
Sapim Race, 14/15g
Tires
[F] Schwalbe Nobby Nic, 27.5x2.25 [R] Racing Ralph, 27.5x2.25, EVO, Snakeskin, TL Easy
Brakes
Brakes
SRAM Guide R, hydraulic disc, 160mm
Brake Levers
SRAM Guide R
Cockpit
Stem
Giant Contact
Handlebar
Giant Contact Trail, 31.8mm
Seat
Saddle
Liv Contact Forward
Seatpost
Giant Contact SL Switch-R Trail, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.49 mm | 1.45 mm | 1.45 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 625 mm | 640 mm | 660 mm | 671 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 84 mm | 84 mm | 84 mm | 84 mm |
| Stack | 573 mm | 578 mm | 587 mm | 597 mm |
| Reach | 375 mm | 388 mm | 405 mm | 412 mm |
| Top Tube Length | 546 mm | 566 mm | 586 mm | 596 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 345 mm | 390 mm | 440 mm | 490 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1050 mm | 1065 mm | 1085 mm | 1096 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 653 mm | 683 mm | 717 mm | 750 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Pique Advanced 2 completes the Liv Pique model. Liv released 32 bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Liv Pique 3 2017 is the most economical model, with a starting price of 2375$. Liv Pique Advanced 0 2017 on the other hand costs 8975$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3300$. In conclusion, this bike price is 19.48% more expensive than the price of the average Trail bike.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is RockShox Deluxe RT, with a travel distance of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Pique Advanced 2 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Pique Advanced 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Liv Pique Advanced 2 bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
