Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 60mm -
Fork SunTour XCT
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
115cm - 130cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminium
Suspension Fork
SR XCT L20, coil, 60mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
N/A
Shift Levers
Shimano REVOSHIFT, 1x7
Cassette
Shimano CS-HG200, 12x32
Crank
Alloy forged, 30t, 127mm
Bottom Bracket
Cartridge
Chain
KMC Z7
Pedals
Platform
Wheels
Front Hub
Giant Disc, 28h, QR, alloy, disc
Rear Hub
Giant Disc, 28h, QR, alloy, disc
Rims
Giant 20", alloy, 28mm inner width
Spokes
Stainless, 14g
Tires
Kenda Karma, 20x2.2"
Brakes
Brakes
Tektro HD-J285, hydraulic [F]160mm, [R]160mm rotors
Brake Levers
Tektro HD-J285
Cockpit
Stem
Forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8mm
Grips
Giant Junior
Seat
Saddle
Giant Jr. Sport
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.44 mm |
| Front Center | 523 mm |
| Rake | 42 mm |
| Trail | 59.8 mm |
| Stack | 444 mm |
| Reach | 309 mm |
| Top Tube Length | 446 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 260 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 361 mm |
| Wheelbase | 883 mm |
| Bottom Bracket Drop | 20 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 130 cm |
About this model
STP 20 FS Liv is part of the Liv Stp model. 12 bikes variations carry this model name so far. Take a sneak peek at all Liv Stp bikes models from 2022, by clicking here.
Model range prices
Liv STP 20 FS Liv 2022 is the most economical model, with a starting price of 445$. Liv STP 26 Liv 2022 on the other hand costs 955$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Youth bikes average price
According to our math, the average price for a trustworthy Youth bike is 278$. However, this doesn’t mean that if you spend less money on a Youth bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2022 and its price was 445$. If we compare this with the average Youth bike cost we notice that the price is 60.07% higher.
STP 20 FS Liv components
Fork
This bike has the SunTour XCT fork installed. The fork’s travel is 60mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Liv STP 20 FS Liv 2022, has a 20″ aluminum model. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The STP 20 FS Liv comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Liv STP 20 FS Liv 2022 is available in one size only. In conclusion, make sure it fits you, or look for another model.
