Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
Regular
140cm - 160cm
LG
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade aluminium
Suspension Fork
RockShox Recon Silver RL, 15x110mm 120mm, with remote lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore RD-M5120
Front Derailleur
N/A
Shift Levers
Shimano Deore, 1x10
Cassette
Shimano CSM-4100, 11x46
Crank
Alloy forged, 30t, Regular 155mm, Large 165mm
Bottom Bracket
Cartridge
Chain
KMC X10
Pedals
Platform
Wheels
Front Hub
Giant Disc, 28h, QR, alloy, disc
Rear Hub
Giant Disc, 28h, QR, alloy, disc
Rims
Giant 26", alloy
Spokes
Stainless, 14g
Tires
Maxxis Ardent, 26x2.25"
Brakes
Brakes
Tektro TDK143, hydraulic [F]160mm, [R]160mm rotors
Brake Levers
Tektro TDK143
Cockpit
Stem
Forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8mm
Grips
Giant Sole-O
Seat
Saddle
Giant Sport
Seatpost
Alloy, two-bolt, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Regular | LG |
|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.48 mm |
| Bottom Bracket Height | 313 mm | 313 mm |
| Front Center | 653 mm | 684 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98.7 mm | 98.7 mm |
| Stack | 570 mm | 579 mm |
| Reach | 365 mm | 392 mm |
| Top Tube Length | 536 mm | 566 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 340 mm | 390 mm |
| Head Tube Angle | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm |
| Chainstay Length | 426 mm | 426 mm |
| Wheelbase | 1077 mm | 1108 mm |
| Bottom Bracket Drop | 30 mm | 30 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 140 cm | 155 cm |
| Rider Max Height | 160 cm | 170 cm |
About this model
STP 26 Liv is part of the Liv Stp model. Liv launched 12 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Liv STP 20 FS Liv 2022 is the most economical model, with a starting price of 445$. Liv STP 26 Liv 2022 on the other hand costs 955$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 955$. If we compare this with the average Trail bike cost we notice that the price is 189.21% smaller.
Overview of components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the STP 26 Liv model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The STP 26 Liv has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Liv STP 26 Liv bike has 2 sizes, in the range of 140 cm – 170 cm (4.59 ft – 5.58 ft). In conclusion, it won’t take much to find one that’s right for you.
