Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 50mm -
Fork SunTour XCT
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 24” Wheels, IS Seatstay Disc Mount, 135mm Dropouts
Suspension Fork
SR Suntour XCT Jr 24", Pre-Load Adjust Coil Spring, 50mm Travel
Drivetrain
Rear Derailleur
Shimano Altus, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Revo Twist 1x7-Speed
Cassette
Shimano HG-20 7-Speed, 12-32T
Crank
Forged Alloy, 30T, 152mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Marin, Double Wall Alloy
Spokes
14g Stainless Steel
Tires
Vee Tire Crown Gem, 24”x2.25”, Wire Bead
Brakes
Brakes
Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
Brake Levers
Kids Specific Short Reach Alloy Lever
Cockpit
Stem
Marin Alloy, 60mm
Handlebar
Marin Riser, 30mm Rise, 590mm Width
Grips
Marin Dual Density
Headset
FSA, Threaded
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 283 mm |
| Front Center | 548 mm |
| Rake | 40 mm |
| Stack | 508.75 mm |
| Reach | 337.92 mm |
| Top Tube Length | 491 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 321 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 406 mm |
| Wheelbase | 952 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 587 mm |
| Wheels | 24" |
Model Overview
Bayview Trail is part of the Marin Bayview model. Marin released 17 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Marin Bayview Trail 24” 2020 is the most economical model, with a starting price of 439$. Marin Bayview Trail 2020 on the other hand costs 459$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain bikes
According to our math, the average price for a trustworthy Mountain bike is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2020 and its price was 459$. Doing a quick comparison, we notice that Bayview Trail price is 34.2% lower than the average cost of a Mountain bike.
Overview of components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 50mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the Bayview Trail bike is equipped with the 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
