Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 188cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 DSX, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Deore 12-Speed
Front Derailleur
-
Shift Levers
Shimano Deore 12-Speed
Cassette
SunRace 12-speed, 11-51
Crank
Forged Aluminum, 42T Steel Narrow Wide Chainring
Bottom Bracket
Sealed Outboard Bearing
Chain
KMC X12
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum, 100x12mm, Centerlock, 32H
Rear Hub
Forged Aluminum, 142x12mm, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, Disc Specific
Tires
WTB Riddler, 700Cx45mm
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin MiniRiser
Grips
Marin MTB
Headset
FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin DSX
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.43 mm | 1.45 mm |
| Bottom Bracket Height | 279.5 mm | 279.5 mm | 279.5 mm | 279.5 mm |
| Front Center | 612 mm | 648 mm | 673 mm | 698 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 77 mm | 77 mm | 77 mm |
| Stack | 540.4 mm | 568.5 mm | 596.6 mm | 624.7 mm |
| Reach | 376 mm | 401 mm | 416 mm | 431 mm |
| Top Tube Length | 532.1 mm | 565.2 mm | 588.2 mm | 611.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 120 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1020 mm | 1056 mm | 1081 mm | 1106 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 654 mm | 696 mm | 726 mm | 754 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 185 cm |
| Rider Max Height | 169 cm | 179 cm | 188 cm | 193 cm |
About this model
DSX 2 is a Marin Dsx model. Marin released 15 bikes variations of this model so far. You can easily view all of the Marin Dsx bikes models from 2023, here.
Model range prices
The most economical model, the Marin DSX 2023 has a starting price of 899$. Marin DSX FS 2023 on the other hand is the most expensive at 1599$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1289$. Comparing the average cost of a Gravel bike to this one, you will see that DSX 2 price is 91% lower.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
DSX 2 components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The DSX 2 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DSX 2 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Marin DSX 2 bike has 4 sizes, in the range of 157 cm – 193 cm (5.15 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
