Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Suntour GVX
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 188cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
SR/Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts
Drivetrain
Rear Derailleur
Shimano SLX, RD7100, 12-Speed
Front Derailleur
-
Shift Levers
Shimano Deore, SLM6100, 12-Speed
Cassette
Shimano Deore, CSM6100, 12-Speed, 10-51T
Crank
Forged Aluminum, 42T Steel Narrow Wide Chainring
Bottom Bracket
Sealed Outboard Bearing
Chain
KMC X12
Pedals
Marin Oso OE Flat
Wheels
Front Hub
Forged Aluminum, 100x12mm, Disc, 32H
Rear Hub
Shimano Forged Aluminum, 142x12mm, Microspline, Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, Disc Specific, Tubeless Compatible
Tires
Vee Tire Co. Rocket Man, 700Cx44mm
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Mini Riser
Grips
Marin MTB
Headset
FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin DSX
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.42 mm | 1.44 mm | 1.45 mm |
| Bottom Bracket Height | 277.5 mm | 277.5 mm | 277.5 mm | 277.5 mm |
| Front Center | 653 mm | 685 mm | 711 mm | 737 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 579.2 mm | 597.8 mm | 625.7 mm | 653.6 mm |
| Reach | 396 mm | 421 mm | 436 mm | 451 mm |
| Top Tube Length | 563.23 mm | 593.6 mm | 616.6 mm | 639.6 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 150 mm | 180 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1061 mm | 1093 mm | 1119 mm | 1145 mm |
| Bottom Bracket Drop | 82 mm | 82 mm | 82 mm | 82 mm |
| Standover Height | 663 mm | 704 mm | 734 mm | 757 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 185 cm |
| Rider Max Height | 169 cm | 179 cm | 188 cm | 193 cm |
About this model
DSX FS completes the Marin Dsx model. 15 bikes variations carry this model name so far. Take a sneak peek at all Marin Dsx bikes models from 2024, by clicking here.
Model range prices
Marin DSX 2024 is the most economical model, with a starting price of 899$. Marin DSX 3 2024 on the other hand costs 1899$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2024 and its price was 1599$. In conclusion, this bike price is 53.97% lower than the price of the average Gravel bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
DSX FS components
Fork
The Suntour GVX is included from the factory. It has a travel distance of 60mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the DSX FS bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DSX FS comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 157 cm – 193 cm (5.15 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
