Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
149cm - 156cm
SM
153cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
184cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Fitness, 6061 Aluminum, 700C Wheels, Disc Brake, Internal Cable Routing, Fender, Rack and Kickstand Mounts
Suspension Fork
Cr-Mo Steel, Straight Blade, Disc Mount, QR Dropouts, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano TY510
Shift Levers
Shimano Shifter/Brake Lever Combo, 3x7-Speed
Cassette
SunRace 7-Speed, 11-34T
Crank
Alloy Crank, Steel Chainrings, 48/38/28T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Fitness 700Cx35mm
Brakes
Brakes
Mechanical Disc
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy Threadless
Handlebar
Marin Alloy Flat, 31.8mm
Grips
Marin Commute
Headset
FSA, Threadless
Seat
Saddle
Marin Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.41 mm | 1.39 mm | 1.4 mm |
| Bottom Bracket Height | 283.5 mm | 283.5 mm | 283.5 mm | 283.5 mm | 283.5 mm |
| Front Center | 615 mm | 634 mm | 661 mm | 688 mm | 712 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Stack | 554 mm | 568.3 mm | 587 mm | 606 mm | 634.3 mm |
| Reach | 382 mm | 397 mm | 417 mm | 437 mm | 452 mm |
| Top Tube Length | 547 mm | 566.2 mm | 591.8 mm | 617.4 mm | 640.8 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 520 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm | 195 mm | 225 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1047 mm | 1067 mm | 1093 mm | 1120 mm | 1145 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 657 mm | 702 mm | 742 mm | 777 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 153 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 156 cm | 167 cm | 177 cm | 187 cm | 190 cm |
About this model
Fairfax 1 is a Marin Fairfax model. Marin released 57 bikes variations of this model so far. You can easily view all of the Marin Fairfax bikes models from 2024, here.
Model range prices
Marin Fairfax 1 2024 is the most economical model, with a starting price of 499$. Marin Fairfax 3 2024 on the other hand costs 989$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2024 and its price was 499$. Comparing the average cost of a Fitness bike to this one, you will see that Fairfax 1 price is 31.46% smaller.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Fairfax 1 components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The Fairfax 1 2024 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Marin Fairfax 1 bike has 5 sizes, in the range of 149 cm – 190 cm (4.89 ft – 6.23 ft). In short, it won’t be difficult to find the right one for you.
