Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, microSHIFT R9 -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
149cm - 156cm
SM
153cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
184cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Fitness, 6061 Aluminum, 700C Wheels, Relieved Tapered Head Tube and BB, Internal Cable Routing, Disc Specific Forged QR Dropouts, Rear Kickstand Mount, Fender and Rack Mounts
Suspension Fork
Marin Full Carbon w/ Tapered Steerer, QR Dropout, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
microSHIFT R9
Shift Levers
microSHIFT R9 2x9 Flat Bar Road Shifters
Cassette
Shimano, 9-Speed, 11-34T
Crank
Forged Alloy, 48/32T Chainrings, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm ID, 25mm Tall, Disc Specific
Tires
Vee Tire Co. G-Sport, 700Cx35mm, Puncture Protection, Wire Bead
Brakes
Brakes
Hydraulic Disc
Brake Levers
Clark's Clout Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Alloy Flat, 31.8mm
Grips
Marin Ergonomic Locking
Headset
FSA, No.42/CB
Seat
Saddle
Marin Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.41 mm | 1.39 mm | 1.4 mm |
| Bottom Bracket Height | 283.5 mm | 283.5 mm | 283.5 mm | 283.5 mm | 283.5 mm |
| Front Center | 615 mm | 634 mm | 661 mm | 688 mm | 712 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Stack | 554 mm | 568.3 mm | 587 mm | 606 mm | 634.3 mm |
| Reach | 382 mm | 397 mm | 417 mm | 437 mm | 452 mm |
| Top Tube Length | 547 mm | 566.2 mm | 591.8 mm | 617.4 mm | 640.8 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 520 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm | 195 mm | 225 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1047 mm | 1067 mm | 1093 mm | 1120 mm | 1145 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 657 mm | 702 mm | 742 mm | 777 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 153 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 156 cm | 167 cm | 177 cm | 187 cm | 190 cm |
About this model
Fairfax 3 belongs to the Marin Fairfax model. Marin released 57 bikes variations of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Marin Fairfax 1 2024 is the most affordable bike of this model and has a price of 499$. On the other hand, Marin Fairfax 3 2024, is the most expensive and costs 989$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2024 for 989$. Comparing the average cost of a Fitness bike to this one, you will see that Fairfax 3 price is 50.76% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
Fairfax 3 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Marin Fairfax 3 2024, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 149 cm – 190 cm (4.89 ft – 6.23 ft). In short, you can easily find one that suits you.
